Photoelectric Sensor HSE18L-P1G5BA | Through-Beam Design | IP67 & IP69K Rated | Fast Response Time | by SICK
The HSE18L-P1G5BA photoelectric sensor features a through-beam design with a visible red laser light, offering a sensing range of up to 60 meters. Ideal for industrial automation and material handling, this sensor ensures reliable presence detection with a fast response time of ≤ 0.5 ms and a switching frequency of 1,000 Hz. Built to withstand harsh environments, it is IP67 and IP69K rated, making it perfect for demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Sensor HSE18L-P1G5BA | Through-Beam Design | IP67 & IP69K Rated | Fast Response Time | by SICK
Brand: SICK
SKU: 1074780
Alternatively Known As: Through-beam photoelectric sensor, Laser sensor, Industrial object sensor, M18 photoelectric sensor
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range max.: 0 m to 60 m
- Light source: Visible red laser, wavelength 655 nm, Laser class I
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP complementary with light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Cable open end, 2,000 mm, PVC
- Protection class: III
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Enclosure rating: IP67, IP69K
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red laser light
- Sensing range up to 50 meters
- Hybrid housing design with M18 thread diameter
- Signal strength light bar for easy alignment
- IP67 and IP69K rated for harsh environments
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- Complementary PNP switching outputs with light/dark switching modes
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper alignment and secure mounting.
Applications
- Industrial automation for detecting small objects
- Material handling and packaging systems
- Presence detection in manufacturing processes
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67/IP69K housing reduces need for frequent replacements
- Compliance with EMC standards reduces electromagnetic interference
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HSE18L-P1G5BA photoelectric sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
