Photoelectric Sensor WLD4FP-1G312130ZZZ | IP66/IP67 Rated | Dual Lens System | 1000 Hz Switching Frequency | by SICK
The WLD4FP-1G312130ZZZ photoelectric sensor is designed for industrial automation, featuring a dual lens system and a robust IP66/IP67 rated housing. With a sensing range of up to 4.5 m and a fast response time of ≤ 500 µs, it’s perfect for safety and presence detection in manufacturing lines and material handling systems. The PinPoint LED visible red light ensures precise alignment, making it an essential tool for efficient operations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Photoelectric Sensor WLD4FP-1G312130ZZZ | IP66/IP67 Rated | Dual Lens System | 1000 Hz Switching Frequency | by SICK
Brand: SICK
SKU: 1113193
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, SICK WLD4FP sensor, Industrial object sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA without load at 24 V
- Output type: Push-pull PNP/NPN light switching
- Output current max: ≤ 100 mA
- Response time: ≤ 500 µs
- Switching frequency: 1000 Hz
- Protection class: III
- Enclosure rating: IP66 and IP67
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- LED wavelength: 635 nm
- Housing material: Plastic VISTAL®
- Cable: 3-wire, 2 m length, PVC
- Dimensions (H x L x W): 40mm x 12mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system
- Sensing range from 0 m to 4.5 m with recommended range 0.035 m to 3.9 m
- PinPoint LED visible red light with 635 nm wavelength
- BluePilot teach-in button for sensitivity adjustment
- LED indicators for alignment, power, and object detection status
- High switching frequency up to 1000 Hz and fast response time ≤ 500 µs
- Robust plastic VISTAL® housing with IP66/IP67 protection rating
- Wide ambient operating temperature range from -40 °C to +60 °C
- Resistance to cleaning agents certified by ECOLAB
Professional Installation Requirements
- Professional installation by a qualified technician or electrician is recommended to ensure proper alignment, wiring, and compliance with safety standards.
Applications
- Industrial automation for object detection
- Safety and presence detection in manufacturing lines
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient LED light source with long service life of 100,000 hours
- Durable design reduces waste and replacement frequency
- ECOLAB certified resistance to cleaning agents supports sustainable maintenance
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WLD4FP-1G312130ZZZ photoelectric sensor is available for immediate purchase, ideal for industrial automation and safety applications.
