Photoelectric Switch WSE12-3P2431 | Through-Beam Sensor | IP66, IP67, IP69K Rated | Fast Response Time | by SICK
The WSE12-3P2431 Photoelectric Switch is a through-beam sensor designed for industrial automation, offering a sensing range of up to 15 m and a robust metal housing with IP66, IP67, and IP69K ratings. With a fast response time of ≤ 330 µs and a high switching frequency of 1,500 Hz, it's perfect for safety monitoring and material handling applications, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Photoelectric Sensor, Through-beam Sensor, Optical Switch, Industrial Photo Sensor
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 15 m (max 20 m)
- Light source: LED, visible red light, wavelength 640 nm
- Light spot size: Ø 220 mm at 15 m
- Adjustment: Potentiometer, 5 turns
- Angle of dispersion: Approx. 1.5°
- Supply voltage: 10 V DC to 30 V DC
- Current consumption sender: ≤ 30 mA
- Current consumption receiver: ≤ 15 mA
- Protection class: III
- Digital output: PNP, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 330 µs
- Switching frequency: 1,500 Hz
- Housing: Metal with plastic PMMA front screen
- Connection: Male connector M12, 4-pin
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Dimensions (H x L x W): 48.5mm x 42mm x 15.6mm
- Weight: 0.12 kg
Key Features
- Through-beam photoelectric sensor with visible red LED light
- Sensing range up to 15 m, max 20 m
- Light spot size Ø 220 mm at 15 m distance
- Adjustable potentiometer with 5 turns for sensitivity tuning
- High switching frequency of 1,500 Hz and fast response time ≤ 330 µs
- Robust metal housing with IP66, IP67, and IP69K protection ratings
- Operating temperature range from -40 °C to +60 °C
- Digital PNP output with light/dark switching mode
Professional Installation Requirements
- Installation by a qualified electrician or trained technician is recommended to ensure proper setup and compliance with electrical standards.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and conveyor systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Long service life minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WSE12-3P2431 Photoelectric Switch is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
