Pilot Light | 24V AC/DC Green LED | Flush Mount Design | High Visibility | @Pack of 1 | by Clipsal
The Pilot Light is a 24V AC/DC green LED indicator designed for high visibility in industrial control panels and switchboards. With a robust flush mounting design and IP65 ingress protection, it ensures reliable operation in harsh environments. Ideal for machinery status indication, this long-life LED technology minimizes maintenance and energy consumption, making it a smart choice for electrical distribution boards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pilot Light | 24V AC/DC Green LED | Flush Mount Design | High Visibility | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHXB2BV67
Alternatively Known As: XB2BV67 pilot light, Clipsal indicator light, 24V green pilot lamp, panel indicator lamp, LED pilot light
Technical Specifications
- Voltage: 24V AC/DC
- Illumination: Green LED
- Mounting: Flush panel mount
- Lens diameter: 22mm
- Ingress protection: IP65 (front)
- Operating temperature: -25°C to +70°C
- Material: Polycarbonate lens, plastic housing
- Dimensions (H x L x W): 30mm x 50mm x 30mm
- Weight: 0.1 kg
Key Features
- 24V AC/DC green LED indicator
- Flush mounting design
- High visibility illumination
- Long-life LED technology
- Robust construction for industrial environments
Professional Installation Requirements
- Installation by a licensed electrician is required to ensure compliance with Australian electrical standards.
Applications
- Industrial control panels
- Switchboards
- Machinery status indication
- Electrical distribution boards
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- LED technology reduces energy consumption and extends operational life, minimizing maintenance and waste.
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal XB2BV67 24V Green LED Pilot Light Indicator is available for immediate purchase. Ideal for industrial control panels and electrical switchboards.
