PL 16/25 Crimp & Insul Set 4P | 660V-3300V | IP55 Ingress Protection | Stainless Steel by Ausproof

BRAND: Ausproof

SKU: RS1937

$253.00 List price: $314.20

+ −

30 Days Return Delivery Options

The PL 16/25 Crimp & Insul Set 4P is designed for high voltage applications, featuring a voltage range of 660V to 3300V and IP55 ingress protection. Ideal for mining and tunnelling, this durable stainless steel set ensures reliable performance in hazardous environments.

Description

Product Name/Title: PL 16 / 25 Crimp & Insul Set 4P 70 mm^2

Brand: Ausproof

SKU: RS1937

Alternatively Known As: PL Range Crimp and Insulation Set, Ex-certified Industrial Plug, Flameproof Plug and Receptacle Set

Technical Specifications

Voltage Range: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 Tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 Tests of 8.0kA for 0.2 seconds
AC HV Withstand (Phase): 8.6kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 250mm x 300mm x 150mm
Weight: 9 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by qualified personnel trained in handling Ex-certified electrical equipment to ensure safety and compliance with hazardous area regulations.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairability minimizes waste by allowing on-site repairs
Lightweight design reduces material usage and transportation emissions

Warranty Information

Warranty details available upon request from Ausproof, typically covering manufacturing defects.

Available Now

The Ausproof PL 16 / 25 Crimp & Insul Set 4P 70 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
