PL 16 / 25 Crimp & Insul Set 6P 120 mm^2

PL 16/25 Crimp & Insul Set 6P | 660V to 3300V | IP55 Ingress Protection | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1957

$279.10 List price: $346.70

+ −

30 Days Return Delivery Options

The PL 16/25 Crimp & Insul Set 6P is designed for hazardous environments, operating at 660V to 3300V with IP55 ingress protection. Ideal for mining and commercial electrical installations, it features a quick release mechanism and durable stainless steel construction for reliable performance.

Description

Product Name/Title: PL 16 / 25 Crimp & Insul Set 6P 120 mm^2

Brand: Ausproof

SKU: RS1957

Alternatively Known As: Ex-certified plug and receptacle set, Flameproof electrical connectors, Mining electrical connectors, Hazardous area plugs

Technical Specifications

Operating Voltage: 660V to 3300V
Current Ratings: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 120mm x 250mm x 120mm
Weight: 9 kg

Key Features

Quick Release mechanism
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation and maintenance should be performed by qualified electricians trained in hazardous area electrical equipment to ensure safety and compliance.

Applications

Mining and tunnelling operations
Commercial electrical installations
Group 1 hazardous environments requiring Ex-certified equipment

Standards & Compliance

Complies with AS/NZS 1299 for electrical equipment in hazardous areas

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairability minimizes waste by allowing on-site body casting replacement

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PL 16 / 25 Crimp & Insul Set 6P 120 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous area applications.
