PL 19/25 Crimp & Insul Set 4P | 660V-3300V | IP55 Ingress Protection | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1931

$253.00 List price: $314.20

+ −

30 Days Return Delivery Options

The PL 19/25 Crimp & Insul Set 4P is designed for high voltage applications, featuring a voltage range of 660V to 3300V and IP55 ingress protection. Ideal for mining and commercial use, it offers quick release functionality and durable stainless steel construction for reliable performance in hazardous environments.

Description

Product Name/Title: PL 19 / 25 Crimp & Insul Set 4P 25 mm^2

Brand: Ausproof

SKU: RS1931

Alternatively Known As: PL Range Crimp and Insulation Set, Ex-rated Industrial Plug, Flameproof Electrical Connector

Technical Specifications

Voltage Range: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 150mm x 300mm x 250mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation and maintenance should be performed by qualified personnel trained in hazardous area electrical equipment to ensure safety and compliance.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 for electrical equipment in hazardous areas

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Flameproof repairability minimizes waste by allowing on-site body casting replacement.

Warranty Information

Warranty details available upon request from Ausproof, typically covering manufacturing defects.

Available Now

The Ausproof PL 19 / 25 Crimp & Insul Set 4P 25 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
