PL Comp Ring Kit 20-25mm | 660V to 3300V | IP55 Ingress Protection | Quick Release Mechanism by Ausproof
The PL Comp Ring Kit 20-25mm is designed for hazardous environments, featuring a voltage range of 660V to 3300V and IP55 ingress protection. Ideal for mining and tunnelling operations, this kit ensures safe and reliable electrical connections with its quick release mechanism and durable stainless steel construction.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PL Comp Ring Kit 20-25mm
Brand: Ausproof
SKU: RS2214
Alternatively Known As: Explosion Proof Plug Kit, Flameproof Electrical Connector, Mining Plug and Receptacle Kit, Ex Rated Plug Kit
Technical Specifications
- Operating Voltage: 660V to 3300V
- Current Ratings: 300A and 425A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
- AC High Voltage Withstand (Phase): 8.6kV for one minute
- AC High Voltage Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Rated for 300A and 425A
- Plug Weight: 9.0 kg
- Receptacle Weight: 10.7 kg
- Dimensions (H x L x W): 200mm x 250mm x 200mm
- Weight: 10.7 kg
Key Features
- Quick Release mechanism
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Professional installation by qualified electricians trained in hazardous area electrical equipment is required to ensure safety and compliance.
Applications
- Mining and tunnelling operations
- Commercial applications
- Group 1 hazardous environments requiring explosion-proof electrical connections
Standards & Compliance
- Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements
- Flameproof repairable design minimizes waste by allowing on-site repairs
- High ingress protection (IP55) ensures long service life in harsh environments
Warranty Information
Warranty details available upon request from Ausproof, typically covering manufacturing defects.
Available Now
The Ausproof PL Comp Ring Kit 20-25mm is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring explosion-proof electrical connections.
