PL Comp Ring Kit 50-55mm | 660V to 3300V | IP55 Ingress Protection | Stainless Steel by Ausproof

BRAND: Ausproof

SKU: RS1622

$83.90 List price: $104.20

+ −

30 Days Return Delivery Options

The PL Comp Ring Kit 50-55mm is designed for high voltage applications, operating between 660V to 3300V with IP55 ingress protection. Ideal for mining and commercial hazardous environments, this stainless steel kit features a quick release mechanism and single piece contacts for enhanced safety and reliability.

Description

Product Name/Title: PL Comp Ring Kit 50-55mm

Brand: Ausproof

SKU: RS1622

Alternatively Known As: PL Range Plug and Receptacle Kit, Ex-rated Stainless Steel Electrical Connector, Flameproof Plug Kit

Technical Specifications

Operating Voltage: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Configurations: 4-pin or 6-pin
Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 55mm x 55mm x 55mm
Weight: 10.7 kg

Key Features

Quick Release mechanism
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation should be performed by qualified electricians trained in hazardous area electrical equipment to ensure compliance and safety.

Applications

Mining and tunnelling operations
Commercial applications in Group 1 hazardous environments
Industrial low voltage electrical connections requiring flameproof equipment

Standards & Compliance

Complies with AS/NZS 1299 for flameproof enclosures and electrical equipment in hazardous areas

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairable design minimizes waste by allowing on-site body casting replacement

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PL Comp Ring Kit 50-55mm is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
