PL Comp Ring Kit 60-65mm | 660V to 3300V | IP55 Rated | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1624

$83.90 List price: $104.20

+ −

30 Days Return Delivery Options

The PL Comp Ring Kit 60-65mm is designed for high voltage applications, operating between 660V to 3300V with an IP55 rating. Ideal for mining and commercial hazardous environments, it features a quick release mechanism and durable stainless steel construction for reliable performance.

Description

Product Name/Title: PL Comp Ring Kit 60-65mm

Brand: Ausproof

SKU: RS1624

Alternatively Known As: PL Range Plug and Receptacle Kit, Ex-rated Stainless Steel Electrical Connector, Mining Grade Plug Kit

Technical Specifications

Operating Voltage: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests at 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests at 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Plug Weight: 9.0 kg
Receptacle Weight: 10.7 kg
Dimensions (H x L x W): 65mm x 65mm x 65mm
Weight: 10.7 kg

Key Features

Quick Release mechanism
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by qualified personnel trained in hazardous area electrical equipment to ensure compliance with safety standards and proper flameproof assembly.

Applications

Mining and tunnelling operations
Commercial applications in Group 1 hazardous environments
Industrial low voltage stainless steel electrical connections

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairability minimizes waste by allowing on-site body casting replacement

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PL Comp Ring Kit 60-65mm is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
