PL QR 3300V 300A 6P Receptacle (270) 25-C

PL QR 3300V 300A 6P Receptacle | 660V to 3300V | IP55 Rated | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1548QR

$2,293.50 List price: $2,848.50

+ −

30 Days Return Delivery Options

The PL QR 3300V 300A 6P receptacle is designed for high-voltage applications, operating between 660V to 3300V with an IP55 rating. Ideal for mining and tunnelling, it features quick release functionality and durable stainless steel construction for reliable performance in hazardous environments.

Description

Product Name/Title: PL QR 3300V 300A 6P Receptacle (270) 25-C

Brand: Ausproof

SKU: RS1548QR

Alternatively Known As: PL Range Receptacle, Ex-certified 300A Receptacle, Quick Release 6 Pin Receptacle, Mining Electrical Receptacle

Technical Specifications

Operating Voltage: 660V to 3300V
Current Rating: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC HV Withstand (Phase): 8.6kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Plug Weight: 9.0 kg
Dimensions (H x L x W): 300mm x 150mm x 200mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by a qualified electrician experienced with Ex-certified equipment and hazardous environment standards.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Easy flameproof repair reduces waste and downtime.

Warranty Information

Standard manufacturer warranty applies. Please contact Ausproof for specific warranty details.

Available Now

The Ausproof PL QR 3300V 300A 6P Receptacle is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
