Pleo LED Neon Flex 14.4W/m 24V IP67 5000K Per Metre Domus
Domus Pleo LED neon flex, 14.4W/m, 24V DC, IP67, CRI90, 5000K, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Pleo 14.4-T Neon Flex, LED Neon Rope Light, Flexible LED Strip Light, Top View Neon Flex
- Power Consumption: 14.4W per metre
- Input Voltage: 24V DC
- Colour Temperature: 5000K
- Luminous Output: 1253 lm per metre
- Colour Rendering Index: ≥90 CRI
- LED Type: SMD
- LED Density: 140 LEDs per metre
- Light Direction: Top view
- Beam Angle: 120°
- Ingress Protection: IP67
- Cutting Increment: 50mm
- Dimming: Yes
- Operating Temperature: -15°C to 85°C
- Wiring: Parallel
- Required Driver: 24V DC constant-voltage LED driver
- Construction: Flexible polyurethane enclosure
- Supply Length: 1 metre
- Mounting: Supplied with mounting clips
- Dimensions (H x L x W): 10mm x 1000mm x 10mm
- Weight: 0.15 kg
- Continuous neon-style illumination with a smooth, seamless appearance
- Top-view light emission for horizontal architectural applications
- High CRI90 output for improved colour rendering
- IP67-rated flexible polyurethane enclosure for suitable indoor and outdoor applications
- Low-voltage 24V DC operation
- Dimmable when used with a compatible driver and control system
- Can be cut at marked 50mm intervals
- Suitable for coves, walls, windows, signage and architectural features
- Designed for use with a compatible 24V constant-voltage driver
- Installation should be performed by a licensed electrician where the 24V driver is connected to mains power. Use a compatible 24V DC constant-voltage driver, observe the 50mm cut points, and seal all cut ends, joins and terminations to maintain the IP67 rating.
- Architectural cove lighting
- Signage and display lighting
- Wall and window illumination
- Outdoor architectural features
- Commercial and residential accent lighting
- Ceiling and floor coves
- Decorative linear lighting installations
- AS/NZS 60529: Applicable to the IP67 enclosure protection classification
- AS/NZS 60598.1: General requirements and tests applicable where the strip is incorporated into a luminaire installation
- AS/NZS 61347.1 and AS/NZS 61347.2.13: Applicable to the compatible LED controlgear or driver
- LED technology provides efficient, low-voltage illumination compared with traditional neon lighting
- Long-life solid-state construction can reduce replacement frequency and associated waste
- Polyurethane enclosure and electronic components should be disposed of through appropriate electrical and e-waste recycling channels
- Dimming compatibility can reduce energy consumption when operated below full output
Domus Lighting warranty: 3-year replacement warranty for residential LED strips and 12-month replacement warranty for commercial LED strips, subject to licensed installation, approved distribution, correct installation and use in accordance with the product guidelines.
Available through Domus Lighting and authorised Australian lighting distributors, supplied as a 1-metre 5000K variant.
