Pleo-Vivid LED Neon Flex 9.6W/m 24V Blue Per Metre Domus
Domus Pleo-Vivid LED neon flex, 9.6W/m, 24V DC, CRI90, blue, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Blue LED Neon Flex, Blue LED Strip Light, Top-View LED Neon Strip, Fixed-Colour LED Strip
- Power Consumption: 9.6W per metre
- Input Voltage: 24V DC
- Colour: Vivid blue
- LED Type: SMD
- LED Density: 140 LEDs per metre
- Colour Rendering Index: CRI90
- Ingress Protection: IP67
- Beam Angle: 165°
- Cutting Increment: 50mm
- Maximum Continuous Run: 5m with one-end feed; 10m with two-end feed
- Dimming: Yes, with a suitable compatible driver or controller
- Operating Temperature: -15°C to 85°C
- Driver Requirement: 24V DC constant-voltage LED driver
- Supplied Accessories: Mounting clips
- Dimensions (H x L x W): 11mm x 1000mm x 10mm
- Weight: 0.12 kg
- Fixed vivid blue light output
- Top-view neon flex design for clear forward-facing illumination
- IP67-rated flexible enclosure for indoor and outdoor applications
- Low-voltage 24V DC operation
- Cuttable in 50mm increments
- Suitable for dimming with compatible control equipment
- Supplied with mounting clips
- Sold by the metre
- Installation and connection of the 24V DC driver to mains power should be performed by a licensed electrician in accordance with AS/NZS 3000 and the manufacturer's installation requirements. Use a correctly sized 24V DC constant-voltage driver.
- Signage and illuminated lettering
- Facade edges and architectural outlines
- Feature lighting and decorative installations
- Retail, hospitality and commercial interiors
- Outdoor accent lighting where the IP67 rating is suitable
- Cove, wall and ceiling-edge lighting
- AS/NZS 60598.2.21: Particular requirements for rope lights and flexible enclosed lighting products; verify product certification for the intended installation
- AS/NZS 3000:2018: Electrical installations — Australian/New Zealand Wiring Rules, relevant to driver connection and installation wiring
- LED technology provides efficient illumination at 9.6W per metre
- 24V DC operation supports efficient low-voltage lighting system design
- Long flexible lengths and 50mm cut increments can help reduce installation offcuts
- The LED light source contains no mercury associated with fluorescent lamps
Domus Lighting warranty: 3-year replacement warranty for residential LED strips and 12-month replacement warranty for commercial LED strips, subject to installation by a licensed electrician, approved installation practices, proof of purchase and the current Domus warranty conditions.
Available through Domus Lighting and authorised Australian lighting retailers and electrical wholesalers.
