Pleo-Vivid LED Neon Flex 9.6W/m 24V Green Per Metre Domus
Domus Pleo-Vivid LED neon flex, 9.6W/m, 24V DC, CRI90, green, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Green LED Neon Flex, Green LED Strip Light, Fixed-Colour LED Strip, Top-View LED Neon Strip
- Input Voltage: 24V DC
- Power Consumption: 9.6W per metre
- Light Colour: Vivid green
- Colour Rendering Index: CRI90
- LED Type: SMD
- LED Density: 140 LEDs per metre
- Ingress Protection: IP67
- Beam Angle: 165°
- Cutting Increment: 50mm
- Dimming: Yes, with a compatible driver
- Maximum Continuous Run: 5m with one-end driver feed; 10m with two-end driver feed
- Operating Temperature: -15°C to 85°C
- Product Length: Sold per metre; 20m roll option available
- Driver Requirement: Requires a 24V DC constant-voltage LED driver
- Dimensions (H x L x W): 10mm x 1000mm x 11mm
- Weight: 0.18 kg
- Vivid fixed green light output
- Top-view LED neon flex construction
- IP67-rated for indoor and outdoor applications
- 140 SMD LEDs per metre for consistent illumination
- Dimmable when paired with a suitable 24V DC driver
- Can be cut in 50mm increments
- Wide 165° beam angle for smooth, uniform light distribution
- Supplied with mounting clips
- Suitable for signage, façades, outlines and feature lighting
- Installation should be carried out by a licensed electrician using a compatible 24V DC constant-voltage LED driver. Outdoor connections must maintain the required IP rating, and installation should follow the manufacturer's instructions and AS/NZS 3000:2018.
- Signage and illuminated lettering
- Façade outlines and architectural accents
- Retail and commercial feature lighting
- Indoor decorative lighting
- Outdoor edge, outline and display lighting
- Entertainment, hospitality and event installations
- AS/NZS 3000:2018 Electrical installations applies to the associated wiring, driver and installation work.
- AS/NZS 60598.2.21 is the relevant Australian/New Zealand product standard category for rope lights; product-specific certification or declaration should be confirmed with Domus Lighting.
- 9.6W/m LED technology can reduce energy consumption compared with many conventional decorative lighting sources.
- 24V DC operation supports efficient low-voltage lighting system design when paired with an appropriately sized driver.
- Long-lasting LED construction can reduce replacement frequency and associated material waste when correctly installed and operated.
Three-year replacement warranty for residential applications and 12-month replacement warranty for commercial applications, subject to Domus Lighting's warranty conditions. Warranty eligibility requires installation by a licensed electrician and compliance with the installation guidelines.
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting retailers.
