Pleo-Vivid LED Neon Flex 9.6W/m 24V Red Per Metre Domus
Domus Pleo-Vivid LED neon flex, 9.6W/m, 24V DC, CRI90, red, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Red LED Neon Flex, Fixed-Colour LED Strip, IP67 LED Strip Light, Top-View LED Neon Strip
- Power Consumption: 9.6W per metre
- Input Voltage: 24V DC
- Colour: Vivid red
- LED Type: SMD
- LED Density: 140 LEDs per metre
- Beam Angle: 165°
- Ingress Protection: IP67
- Cutting Increment: 50mm
- Maximum Continuous Run: 5m with one-end driver feed; 10m with two-end driver feed
- Dimming: Yes, with a suitable compatible driver
- Operating Temperature: -15°C to 85°C
- Driver Requirement: 24V DC constant-voltage LED driver
- Supply Length: Sold per metre; product datasheet also specifies a 20m maximum roll length
- Colour Rendering Index: CRI90 as listed in the supplied product specification
- Manufacturer Variant: Domus item 20063, Vivid Red
- Dimensions (H x L x W): 10mm x 1000mm x 11mm
- Weight: 0.2 kg
- Fixed vivid-red colour output for signage, outlines and feature lighting
- Top-view LED strip format for forward-facing illumination
- IP67-rated construction for suitable indoor and outdoor applications
- Cuttable in 50mm increments for installation flexibility
- 165° beam angle for broad, even light distribution
- Dimmable when paired with a compatible 24V DC driver
- Supplied with mounting clips
- Suitable for facade edges, signs, architectural outlines and feature lighting
- Installation and connection to the 24V DC driver should be completed by a licensed electrician. Use a compatible constant-voltage driver and install in accordance with AS/NZS 3000 and the manufacturer's installation requirements. Domus warranty eligibility requires installation by a licensed electrician. ([domuslighting.com.au](https://www.domuslighting.com.au/wp-content/uploads/2026/01/Warranty-Statement-Revised-09-01-2026.pdf))
- Signage and illuminated lettering
- Facade edge and outline lighting
- Architectural feature lighting
- Retail, hospitality and entertainment displays
- Indoor and outdoor accent lighting
- Ceiling, wall and structural feature illumination
- AS/NZS 3000:2018 Wiring Rules are applicable to the electrical installation of the 24V DC lighting system.
- AS/NZS 60598.1:2017 provides relevant general safety requirements for luminaires; product-specific certification is not stated on the manufacturer's product page.
- 9.6W per metre power consumption can reduce energy use compared with higher-wattage LED strip alternatives.
- 24V DC extra-low-voltage operation supports efficient low-voltage lighting system design.
- Dimmability allows light output and energy consumption to be reduced when full brightness is not required.
- IP67 construction can support longer service life in suitable installations by protecting the strip from dust and moisture.
Domus lists a 3-year replacement warranty for LED strips in residential applications and a 12-month replacement warranty for commercial applications. Warranty claims require proof of purchase, licensed-electrician installation and compliance with installation guidelines. ([domuslighting.com.au](https://www.domuslighting.com.au/product/pleo-vivid-t/))
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting retailers. ([domuslighting.com.au](https://www.domuslighting.com.au/product-category/pleo-led-neon-series/?utm_source=openai))
