Pleo-Vivid LED Neon Flex 9.6W/m 24V Yellow Per Metre Domus
Domus Pleo-Vivid LED neon flex, 9.6W/m, 24V DC, CRI90, yellow, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Yellow LED Neon Flex, 24V LED Strip Light, Fixed-Colour LED Strip, Top-View LED Neon Strip
- Power Consumption: 9.6W per metre
- Input Voltage: 24V DC
- Light Source: 140 SMD LEDs per metre
- Colour: Vivid Yellow
- Colour Rendering Index: CRI 90
- IP Rating: IP67
- Beam Angle: 165°
- Cutting Increment: 50mm
- Maximum Continuous Run: 5m with one-end feed; 10m with two-end feed
- Dimming: Yes, with a suitable compatible driver
- Operating Temperature: -15°C to 85°C
- Driver Requirement: 24V DC constant-voltage LED driver
- Supply Format: Sold per metre; 20m roll availability
- Product Variant: Item 20066
- Luminous Efficacy: 63 lm/W for vivid yellow
- Dimensions (H x L x W): 11mm x 1000mm x 8mm
- Weight: 0.12 kg
- Fixed vivid-yellow output for signage and feature lighting
- Top-view LED orientation for front-facing illumination
- IP67 construction for suitable indoor and outdoor applications
- Flexible polyurethane-enclosed strip supplied with mounting clips
- 50mm cut increments for installation flexibility
- Dimmable when paired with a compatible 24V DC driver
- Suitable for façade edges, outlines, signage and architectural feature lighting
- Domus specifies a three-year warranty for the PLEO-VIVID-T series
- Installation of the 24V DC driver and associated electrical wiring should be performed by a licensed electrician. Use a compatible constant-voltage driver, observe the 5m single-end or 10m two-end feed limits, and install in accordance with the manufacturer's instructions. Domus warranty eligibility requires installation by a licensed electrician. ([domuslighting.com.au](https://www.domuslighting.com.au/wp-content/uploads/2026/01/Warranty-Statement-Revised-09-01-2026.pdf))
- Indoor feature lighting
- Outdoor architectural and façade outlines
- Signage and display illumination
- Cove, edge and contour lighting
- Retail, hospitality and commercial decorative lighting
- Residential feature lighting
- AS/NZS 60598.2.23:2021 – applicable extra-low-voltage lighting-system requirements; final applicability depends on the completed luminaire or installation assembly. ([inus04aapb1h3nprod.dxcloud.episerver.net](https://inus04aapb1h3nprod.dxcloud.episerver.net/en-us/standards/as-nzs-60598-2-23-2021-115874_saig_as_as_3028800/))
- AS/NZS 3000:2018 – relevant electrical installation requirements for the 24V driver, wiring and final installation
- Low-voltage 24V DC operation supports efficient LED system design
- LED technology provides fixed-colour illumination without neon gas or high-voltage tube operation
- IP67 construction and a stated three-year warranty may support longer service life and reduced replacement waste
- Sold by the metre helps reduce material waste where shorter lengths are required
Domus lists the PLEO-VIVID-T series as backed by a three-year warranty. Domus' current warranty statement provides LED strips with a three-year replacement warranty for residential applications and a 12-month replacement warranty for commercial applications, subject to licensed-electrician installation and other conditions. ([domuslighting.com.au](https://www.domuslighting.com.au/product/pleo-vivid-t/))
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting retailers. ([domuslighting.com.au](https://www.domuslighting.com.au/resources/?utm_source=openai))
Lighting Requirement Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
