Pleo-Vivid Micro LED Neon Flex 9.6W/m 24V Yellow Per Metre Domus
Domus Pleo-Vivid micro LED neon flex, 9.6W/m, 24V DC, CRI90, yellow, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Pleo-Vivid M-S Yellow Neon Flex, Micro LED Neon Strip, Yellow LED Neon Flex, Static-Colour LED Strip
- Product Type: Side-view static-colour LED neon flex
- Light Colour: Vivid yellow
- Input Voltage: 24V DC
- Power Consumption: 9.6W per metre
- LED Type: SMD LED
- LED Density: 140 LEDs per metre
- Colour Rendering Index: CRI 90
- Ingress Protection: IP67
- Beam Angle: 110°
- Cutting Increment: 50mm
- Dimming: Yes, with a compatible 24V DC driver or controller
- Maximum Continuous Run: 5m single-feed or 10m dual-feed
- Operating Temperature: -15°C to 85°C
- Supply Format: Sold per metre
- Driver Requirement: 24V DC constant-voltage LED driver required
- Dimensions (H x L x W): 6.5mm x 1000mm x 8mm
- Weight: 0.18 kg
- Vivid yellow static-colour illumination
- Micro side-view neon flex format for compact installations
- IP67 protection for suitable indoor, damp-area and outdoor applications
- 140 SMD LEDs per metre for consistent light output
- Can be cut in 50mm increments
- Dimmable with compatible control equipment
- Supports runs up to 5m from one end or 10m with dual-end feeding
- Suitable for facades, signage, outlines and feature lighting
- Installation should be completed by a licensed electrician, particularly where the 24V DC driver is connected to mains power. Use a compatible constant-voltage driver, follow the manufacturer's installation instructions and seal all cut ends and connections to maintain the intended IP rating.
- Architectural facade outlining
- Signage and sign lettering
- Retail and hospitality feature lighting
- External building and landscape outlines
- Cove, recess and decorative lighting
- Display, event and entertainment installations
- Applicable lighting system requirements: AS/NZS 60598.1:2017 for general luminaire safety requirements
- Applicable LED controlgear requirements: AS 61347.2.13:2018 for compatible electronic controlgear used with LED modules
- Low-voltage LED technology provides efficient illumination at 9.6W per metre
- LEDs generally offer a long service life, reducing replacement frequency and material waste
- IP67 construction can support extended service life in suitable outdoor and damp environments
- Dimmable operation can reduce energy consumption when full output is not required
Domus lists a 3-year warranty for this product range. Under the current Domus warranty statement, LED strips are covered for 3 years in residential applications and 12 months in commercial applications, subject to licensed-electrician installation, proof of purchase and compliance with installation guidelines.
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting distributors.
