Plex-COB-20-IP67 LED Strip 24V IP67 CRI90 3000K 50m Roll Domus
Domus Plex-COB-20-IP67 LED Strip, 24V DC, IP67, CRI90, 640 LED/m, 3000K, 50m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: COB LED Strip Light, Dotless LED Tape, Waterproof LED Strip, 24V LED Strip Lighting
- Light Source: COB LED
- LED Density: 640 LEDs per metre
- Input Voltage: 24V DC
- Power Consumption: 20W per metre
- Luminous Output: 1520 lm per metre at 3000K
- Colour Temperature: 3000K warm white
- Colour Rendering Index: CRI ≥90
- Beam Angle: 180°
- Ingress Protection: IP67
- Dimming: Yes, with a compatible LED driver and dimmer
- Cutting Increment: 25mm
- Wiring: Parallel
- Maximum Continuous Run: 3m with single-end feed; 6m with feeds at both ends
- Operating Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Rated Life: 50,000 hours
- Required Driver: 24V DC constant-voltage LED driver
- Heat Management: Must be installed on an aluminium heat sink
- Roll Length: 50 metres
- Dimensions (H x L x W): 4.5mm x 50000mm x 12mm
- Weight: 2.2 kg
- COB construction provides a smooth, dotless linear appearance
- IP67 silicone-coated design for waterproof installations
- High CRI90 output for improved colour rendering
- 24V DC operation helps reduce resistive heat over longer runs
- Weldless joint design supports continuity and reliability
- Dimmable with suitable driver and dimming controls
- 25mm cutting increments for installation flexibility
- Compatible with Domus Plex COB connectors and accessories
- Installation should be completed by a licensed electrician using a compatible 24V DC constant-voltage LED driver. Install the strip on an aluminium heat sink, provide suitable waterproof connections for IP67 applications, and follow AS/NZS 3000 and the manufacturer's installation instructions.
- Architectural and feature lighting
- Kitchen, bathroom and laundry lighting
- Bar and restaurant lighting
- Pelmet, cove and joinery lighting
- Commercial interior linear lighting
- Waterproof indoor and outdoor lighting applications where the complete installation maintains the required IP rating
- Applicable lighting safety requirements: AS/NZS 60598.1
- Applicable fixed general-purpose luminaire requirements: AS/NZS 60598.2.1
- Electrical installation should be completed in accordance with AS/NZS 3000
- IP67 classification is based on the IP Code framework of AS/NZS 60529; final IP protection depends on the complete installed system
- LED technology provides efficient illumination compared with conventional halogen and incandescent sources
- Rated life of up to 50,000 hours can reduce replacement frequency and associated waste
- Low-voltage 24V DC operation supports efficient, controlled lighting installations
- COB LED construction provides consistent light output across the strip, supporting targeted linear illumination
Domus Lighting's current warranty statement provides COB LED strips with a 3-year replacement warranty for residential applications, extended to a total of 5 years when used with Domus drivers. Commercial applications receive a 12-month replacement warranty, extended to a total of 2 years when used with Domus drivers. Warranty eligibility requires installation by a licensed electrician and compliance with the manufacturer's installation guidelines.
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting distributors.
