Plex-COB-20-IP67 LED Strip 24V IP67 CRI90 4000K 20m Roll Domus
Domus Plex-COB-20-IP67 LED Strip, 24V DC, IP67, CRI90, 640 LED/m, 4000K, 20m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Domus Plex COB LED Strip, COB LED Tape Light, Dotless LED Strip, 24V IP67 LED Strip
- Input Voltage: 24V DC
- Power Consumption: 20W per metre
- Total Roll Length: 20m
- Colour Temperature: 4000K neutral white
- Colour Rendering Index: CRI90 or higher
- LED Type: COB, 640 LEDs per metre
- Luminous Output: Approximately 1700 lm per metre at 4000K
- Beam Angle: 180 degrees
- Ingress Protection: IP67
- Dimming: Yes, with a compatible LED driver and dimmer
- Cutting Increment: 25mm
- Wiring: Parallel
- Maximum Continuous Run: 3m with single-end feed or 6m with feed at both ends
- Lifespan: 50,000 hours
- Operating Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Required Driver: 24V DC constant-voltage LED driver
- Installation Base: Aluminium heat sink required
- Dimensions (H x L x W): 4.5mm x 20000mm x 12mm
- Weight: 2 kg
- True dotless COB illumination for a continuous linear appearance
- High-density 640 LEDs per metre
- High colour rendering with CRI90 performance
- IP67 silicone-coated construction for waterproof installations when correctly connected
- 24V DC operation reduces resistive heat compared with lower-voltage strip systems
- 25mm cutting increments for installation flexibility
- Suitable for dimming with compatible control equipment
- Designed for kitchens, bathrooms, laundries, bars, restaurants and indoor highlighting applications
- Installation should be completed by a licensed electrician using a suitably rated 24V DC constant-voltage LED driver. Mount the strip on an aluminium heat sink, use compatible IP-rated connections, and follow the manufacturer's installation instructions. The strip must not be operated at its full 20m length from a single feed; use appropriate power injection and driver sizing for longer runs.
- Architectural cove and linear lighting
- Kitchen, bathroom and laundry feature lighting
- Retail, hospitality and restaurant highlighting
- Display cabinetry and shelving
- Commercial interior accent lighting
- Water-resistant indoor and sheltered outdoor lighting installations
- LED technology provides lower energy consumption than equivalent conventional lighting sources
- Long rated lifespan of 50,000 hours can reduce replacement frequency and associated waste
- 24V DC operation and aluminium heat sinking support improved thermal management and system efficiency
- The separate strip-and-driver design can allow individual components to be replaced rather than replacing a complete integrated fitting
Domus Lighting warranty: 3-year replacement warranty for COB LED strips in residential applications, extended to a total of 5 years when used with Domus drivers. Commercial applications receive a 12-month replacement warranty, extended to a total of 2 years when used with Domus drivers. Warranty eligibility requires installation by a licensed electrician and installation in accordance with Domus guidelines, including use of an aluminium heat sink.
Available through Domus Lighting and authorised Australian electrical and lighting distributors.
