Plex-COB-20-IP67 LED Strip 24V IP67 CRI90 4000K 50m Roll Domus
Domus Plex-COB-20-IP67 LED Strip, 24V DC, IP67, CRI90, 640 LED/m, 4000K, 50m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: COB LED Strip Light, IP67 LED Tape, 24V LED Strip, Dotless LED Strip
- Input Voltage: 24V DC
- Power Consumption: 20W per metre
- Colour Temperature: 4000K neutral white
- Luminous Output: 1700 lm per metre
- Colour Rendering Index: CRI ≥90
- LED Type: COB, 640 LEDs per metre
- Ingress Protection: IP67
- Beam Angle: 180°
- Dimming: Yes, with a suitable LED driver and dimmer
- Lifespan: 50,000 hours
- Wiring: Parallel
- Cutting Increment: 25mm
- Maximum Run: 3m with single-end feed; 6m with feeds at both ends
- Operating Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Required Driver: 24V DC constant-voltage LED driver
- Installation Requirement: Must be installed on an aluminium heat sink to maintain warranty validity
- Dimensions (H x L x W): 4.5mm x 50000mm x 12mm
- Weight: 5 kg
- COB technology provides a continuous dotless light appearance
- High colour rendering with CRI ≥90
- IP67-rated construction for protection against dust and temporary water immersion
- 24V DC operation supports reduced resistive losses compared with lower-voltage strips
- Dimmable with compatible constant-voltage driver and dimmer
- 25mm cutting increments for flexible installation
- Suitable for kitchens, bathrooms, laundries, bars, restaurants and indoor highlighting applications
- Installation should be carried out by a suitably qualified electrician. Use a correctly sized 24V DC constant-voltage LED driver, install the strip on an aluminium heat sink, seal all IP67 connections appropriately, and observe AS/NZS 3000 requirements for the associated electrical installation. The mains-connected driver must be installed in accordance with applicable electrical regulations.
- Architectural and concealed feature lighting
- Kitchen, bathroom and laundry lighting
- Bar and restaurant highlighting
- Retail and display lighting
- Joinery, cabinetry and cove lighting
- Indoor areas requiring high-CRI neutral-white illumination
- AS/NZS 3000:2018 for the installation of the 24V SELV lighting circuit and associated driver
- AS/NZS 60598.1:2017 may apply where the LED strip is incorporated into a complete luminaire or lighting assembly
- IEC 60529 IP67 classification is relevant to the stated ingress-protection rating
- LED technology provides high luminous output at 20W per metre, supporting efficient lighting designs
- 50,000-hour rated life can reduce replacement frequency and associated waste
- 24V operation can reduce resistive losses in suitable longer-run lighting installations
- Low-voltage operation reduces electrical energy requirements compared with equivalent mains-voltage strip systems
Domus COB LED strips have a 3-year replacement warranty for residential use, increasing to a total 5-year replacement warranty when used with Domus drivers. Commercial coverage is 12 months, increasing to a total 2 years when used with Domus drivers. Warranty conditions include installation on an aluminium heat sink and installation by a licensed electrician.
Available through Domus Lighting and authorised Australian lighting distributors.
Lighting Requirement Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
