Plex-COB-20-IP67 LED Strip 24V IP67 CRI90 5000K 20m Roll Domus
Domus Plex-COB-20-IP67 LED Strip, 24V DC, IP67, CRI90, 640 LED/m, 5000K, 20m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Domus PLEX COB IP67 LED Strip, COB LED Tape Light, Waterproof 24V LED Strip, Dotless LED Strip
- Input Voltage: 24V DC
- Power Consumption: 20W per metre
- Colour Temperature: 5000K
- Lumen Output: 1700lm per metre
- Colour Rendering Index: CRI ≥90
- LED Type: COB, 640 LEDs per metre
- Beam Angle: 180°
- Ingress Protection: IP67
- Dimming: Yes, with compatible LED driver and dimmer
- Lifespan: 50,000 hours
- Wiring: Parallel
- Cutting Increment: 25mm
- Maximum Continuous Run: 3m with one-end driver feed; 6m with two-end driver feed
- Required Driver: 24V DC constant-voltage LED driver
- Working Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Variant: 24067
- Roll Length: 20m
- Dimensions (H x L x W): 4.5mm x 20000mm x 12mm
- Weight: 2 kg
- COB technology provides a smooth, true dotless appearance
- IP67 silicon-coated construction for waterproof installations
- High CRI90 light quality for accurate colour rendering
- 5000K white colour temperature
- 180° beam angle for broad linear illumination
- Dimmable with a suitable 24V LED driver and dimmer
- 25mm cutting increments for flexible installation
- Weldless joint construction supports continuity and reliability
- Must be installed on an aluminium heat sink to manage heat and preserve warranty coverage
- Suitable for Domus PLEX-COB connectors and accessories
- Installation should be completed by a licensed electrician. Use a compatible 24V DC constant-voltage LED driver, install the strip on an aluminium heat sink, and ensure all IP67 connections, end caps and cable entries are correctly sealed. Follow AS/NZS 3000 and the manufacturer's installation instructions.
- Kitchen and bathroom feature lighting
- Laundry and wet-area accent lighting
- Bar and restaurant linear lighting
- Commercial display and architectural highlighting
- Pelmet, cabinet and joinery lighting
- Indoor or protected outdoor linear lighting applications
- AS/NZS 3000: applicable wiring and installation requirements for low-voltage electrical installations; product-specific certification is not stated by the manufacturer
- AS/NZS 60598.1 and applicable lighting-part requirements may apply to the complete assembled lighting system; manufacturer compliance for this strip alone is not stated
- LED technology provides efficient directional lighting compared with conventional light sources
- 50,000-hour rated lifespan can reduce replacement frequency and associated waste
- 24V operation and parallel wiring support efficient low-voltage lighting system design
- Aluminium heat-sink installation assists thermal management and can extend service life
- LED lighting contains no mercury-based fluorescent lamp source
Domus warranty statement: 3-year replacement warranty for residential applications and 12-month replacement warranty for commercial applications. COB LED strips receive a total 5-year residential replacement warranty, or 2-year commercial replacement warranty, when used with Domus drivers. Warranty eligibility requires licensed electrician installation and compliance with installation instructions, including aluminium heat-sink installation.
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting retailers.
