Plex-COB-20-IP67 LED Strip 24V IP67 CRI90 5000K 50m Roll Domus
Domus Plex-COB-20-IP67 LED Strip, 24V DC, IP67, CRI90, 640 LED/m, 5000K, 50m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: COB LED Strip, Dotless LED Strip, Waterproof LED Tape, 24V LED Strip Lighting
- Input Voltage: 24V DC
- Power Consumption: 20W per metre
- Lumen Output: 1700 lm per metre
- Colour Temperature: 5000K
- Colour Rendering Index: ≥90 CRI
- LED Type: COB, 640 LEDs per metre
- Ingress Protection: IP67
- Beam Angle: 180°
- Dimming: Yes, with suitable driver and dimmer
- Lifespan: 50,000 hours
- Wiring: Parallel
- Cutting Increment: 25mm
- Continuous Run: Maximum 3m with one-end feed or 6m with two-end feed
- Driver Requirement: 24V DC constant-voltage LED driver
- Working Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Strip Width: 12mm
- Strip Height: 4.5mm
- Dimensions (H x L x W): 4.5mm x 50000mm x 12mm
- Weight: 5 kg
- True dotless COB LED appearance
- High colour rendering performance with CRI ≥90
- IP67 waterproof construction for suitable wet-area and outdoor applications
- Uniform 180° linear light distribution
- 24V DC operation reduces resistive heat and supports longer low-voltage runs
- Dimmable when paired with a compatible 24V constant-voltage driver and dimmer
- 25mm cutting sections for installation flexibility
- Must be installed on an aluminium heat sink
- 50m roll format for continuous linear lighting projects
- Installation should be completed by a licensed electrician. Use a compatible 24V DC constant-voltage LED driver, install the strip on an aluminium heat sink, and ensure all IP67 connections, end caps and cable entries are suitably sealed. The 50m roll must be divided into runs within the manufacturer's maximum continuous-run limits.
- Architectural linear lighting
- Kitchen, bathroom and laundry feature lighting
- Commercial bars and restaurants
- Display, cabinet and joinery lighting
- Indoor highlighting and cove lighting
- Suitable waterproof linear lighting installations where IP67 protection is required
- AS/NZS 60598.1:2017 is relevant to the safety assessment of the complete luminaire or assembled lighting installation; product-level compliance is not stated in the supplied manufacturer documentation.
- AS/NZS 61347.2.13:2018 is relevant to the required LED controlgear or driver rather than the LED strip itself.
- AS/NZS 3000:2018 applies to the electrical installation and connection of the LED driver and associated wiring.
- LED technology provides lower energy consumption than equivalent traditional linear light sources
- 50,000-hour rated life can reduce replacement frequency and associated waste
- 24V DC operation can reduce resistive heat losses in suitable low-voltage installations
- COB construction provides consistent light output across long linear installations
- The strip can be cut to required lengths, helping reduce installation offcuts
Domus COB LED strips have a 3-year replacement warranty for residential applications, or a 12-month replacement warranty for commercial applications. When used with Domus drivers, the warranty extends to a total of 5 years residential or 2 years commercial, subject to licensed-electrician installation, compliance with installation instructions and the requirement to install the strip on an aluminium heat sink.
Available through Domus Lighting and authorised Australian electrical and lighting distributors. Confirm current stock and lead time with the distributor.
