Plex-COB-20 LED Strip 24V IP54 CRI90 3000K 20m Roll Domus
Domus Plex-COB-20 LED Strip, 24V DC, IP54, CRI90, 640 LED/m, 3000K, 20m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Domus PLEX COB 20 LED Strip, COB LED Tape Light, Dotless LED Strip, 24V Warm White LED Strip
- Input Voltage: 24V DC
- Power Consumption: 20W per metre
- Total Roll Power: 400W for 20m
- Colour Temperature: 3000K warm white
- Lumen Output: 1800 lm per metre
- LED Type: COB, 640 LEDs per metre
- Colour Rendering Index: CRI ≥90
- IP Rating: IP54; indoor use only and suitable for indoor wet areas
- Beam Angle: 180°
- Dimmable: Yes, with a compatible LED driver and dimmer
- Wiring: Parallel
- Cutting Increment: 25mm
- Maximum Continuous Run: 3m with one-end feed or 6m with feeds at both ends
- Required Driver: 24V DC constant-voltage LED driver
- Operating Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Rated Life: 50,000 hours
- Heat Management: Must be installed on an aluminium heat sink
- Roll Length: 20m
- Dimensions (H x L x W): 4.5mm x 20000mm x 12mm
- Weight: 3.5 kg
- True dotless COB LED appearance
- High CRI90 light quality for accurate colour rendering
- 3000K warm white output suitable for residential and commercial interiors
- 24V DC operation supports longer runs with reduced resistive heat
- IP54 protection for indoor applications, including suitable wet-area installations
- 180° beam angle for broad, continuous linear illumination
- 25mm cutting sections for installation flexibility
- Dimmable with suitable 24V LED drivers and dimmers
- Reduced welded-joint areas to improve continuity and reliability
- Compatible with Domus PLEX-COB connectors and aluminium profiles
- A suitably qualified electrician should install the 24V LED driver and any mains-voltage connections. Install the strip on an aluminium heat sink in accordance with Domus instructions; failure to use an aluminium heat sink may void the warranty.
- Kitchen under-cabinet lighting
- Bathroom and laundry feature lighting
- Bars, restaurants and hospitality interiors
- Joinery, shelving and display lighting
- Residential architectural highlighting
- Commercial interior accent lighting
- Linear lighting within compatible aluminium profiles
- AS/NZS 60598.1:2017 may apply to the completed luminaire or lighting assembly; Domus does not state product-level compliance for the LED strip in the available datasheet
- AS/NZS 3000 may apply to the installation of the associated driver and wiring
- LED technology can reduce energy consumption compared with equivalent conventional lighting
- 50,000-hour rated life can reduce replacement frequency and material waste
- 24V DC operation and dimming capability support efficient lighting-system design
- Aluminium heat-sink installation helps manage operating temperature and extend product service life
Domus COB LED strips have a 3-year replacement warranty for residential applications and a 12-month replacement warranty for commercial applications. When used with Domus drivers, the residential warranty can total 5 years and the commercial warranty 2 years. Warranty coverage requires installation by a licensed electrician and correct aluminium heat-sink installation.
Available through Domus Lighting and authorised Australian electrical and lighting distributors.
