Domus Plex-COB-20 LED Strip, 24V DC, IP54, CRI90, 640 LED/m, 4000K, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: COB LED Strip, Dotless LED Strip, 24V LED Tape, Neutral White LED Strip
- Input Voltage: 24V DC
- Power Consumption: 20W per metre
- Lumen Output: 2000 lm per metre
- Colour Temperature: 4000K neutral white
- Colour Rendering Index: ≥90
- LED Type: COB, 640 LEDs per metre
- IP Rating: IP54; indoor use only and suitable for indoor wet areas
- Beam Angle: 180°
- Dimming: Yes, with a compatible LED driver and dimmer
- Lifespan: 50,000 hours
- Wiring: Parallel
- Cutting Increment: 25mm
- Maximum Continuous Run: 3m with one-end feed or 6m with two-end feed
- Required Driver: 24V DC constant-voltage LED driver
- Operating Temperature: -20°C to 50°C
- Installation Requirement: Install on an aluminium heat sink to maintain warranty validity
- Dimensions (H x L x W): 4.5mm x 1000mm x 12mm
- Weight: 0.1 kg
- True dotless COB appearance with uniform linear illumination
- High CRI90 output for accurate colour rendering
- 24V DC operation with reduced resistive heat
- 4000K neutral white colour temperature
- IP54 protection for indoor applications, including suitable wet-area installations
- Dimmable with a compatible 24V LED driver and dimmer
- 25mm cut points for flexible sizing
- Available per metre, with 20m and 50m roll options
- Suitable for Domus fast-fix, L-joint and strip connector accessories
- Installation should be completed by a licensed electrician where required, particularly for the 240V AC supply to the LED driver. Use a compatible 24V DC constant-voltage driver, install the strip on an aluminium heat sink and follow the manufacturer's installation instructions.
- Kitchen and cabinet lighting
- Bathroom and laundry feature lighting
- Bars, restaurants and hospitality interiors
- Pelmet, shelf and joinery lighting
- Architectural and commercial linear lighting
- Indoor accent and highlighting applications
- AS/NZS 60598.1:2017 – general safety requirements for luminaires and completed lighting assemblies
- AS/NZS 60598.2.23:2021 – extra-low-voltage lighting systems, where the completed installation falls within its scope
- LED technology provides high light output at 20W per metre compared with many traditional light sources
- 50,000-hour rated lifespan can reduce replacement frequency and associated waste
- 24V DC operation and parallel wiring can help reduce resistive heat in suitable installations
- Aluminium heat sinks used for installation are durable and recyclable
Domus COB LED strips carry a 3-year replacement warranty for residential applications and a 12-month replacement warranty for commercial applications. When used with Domus drivers, the total replacement warranty increases to 5 years residential or 2 years commercial. Warranty conditions require compliant installation, including use of an aluminium heat sink. ([domuslighting.com.au](https://www.domuslighting.com.au/wp-content/uploads/2026/01/Warranty-Statement-Revised-09-01-2026.pdf))
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting retailers. ([domuslighting.com.au](https://www.domuslighting.com.au/product-category/plex-series/))
