Plex-COB-20 LED Strip 24V IP54 CRI90 5000K 50m Roll Domus
Domus Plex-COB-20 LED Strip, 24V DC, IP54, CRI90, 640 LED/m, 5000K, 50m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Plex COB 20 LED Strip, Domus COB LED Tape Light, 24V COB Strip Light, True Dotless LED Strip
- Product Variant: PLEX-COB-20-50M, variant 24039
- Input Voltage: 24V DC
- Power Consumption: 20W per metre; 1000W total per 50m roll
- Luminous Output: 2000lm per metre
- Colour Temperature: 5000K white
- Colour Rendering Index: CRI ≥90
- LED Type: COB, 640 LEDs per metre
- Beam Angle: 180°
- Ingress Protection: IP54; indoor use and suitable for indoor wet areas
- Dimming: Yes, with compatible LED driver and dimmer
- Cutting Increment: 25mm
- Maximum Continuous Run: 3m with one-end feed or 6m with feed at both ends
- Wiring: Parallel
- Operating Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Lifespan: 50,000 hours
- Required Driver: 24V DC constant-voltage LED driver
- Installation Requirement: Install on an aluminium heat sink; failure to do so may void the warranty
- Dimensions (H x L x W): 2.8mm x 50000mm x 10mm
- Weight: 2.5 kg
- COB technology provides a smooth, true dotless appearance
- High CRI90 output for improved colour accuracy
- 5000K white light suitable for clean, neutral architectural illumination
- 24V DC operation supports reduced resistive heat and longer run lengths
- IP54 construction suitable for indoor applications and wet areas
- Dimmable with a compatible 24V constant-voltage driver and dimmer
- 25mm cutting increments for flexible installation lengths
- Weldless joint design improves reliability and continuity
- Compatible fast-fix, straight, corner and flexible strip connectors
- Available as a 50m roll for large linear lighting installations
- Installation should be performed by a licensed electrician. Use a suitably rated 24V DC constant-voltage LED driver, provide adequate heat dissipation with an aluminium heat sink, and follow applicable wiring and manufacturer installation requirements.
- Architectural linear lighting
- Kitchen, bathroom and laundry lighting
- Bar, restaurant and hospitality feature lighting
- Commercial display and joinery illumination
- Cove, shelf and cabinet lighting
- Indoor wet-area accent lighting
- Large-scale residential and commercial lighting installations
- AS/NZS 60598.1:2017 is applicable to the safety assessment of the completed luminaire or lighting assembly incorporating the LED strip; product-specific compliance is not stated by the manufacturer
- AS/NZS 61347.2.13:2018 is applicable to associated electronic controlgear for LED modules, including the required 24V LED driver
- AS/NZS 3000 applies to the electrical installation and connection of the associated driver and lighting system
- LED technology provides high light output at 20W per metre and can reduce energy consumption compared with many conventional linear lighting sources
- Published 50,000-hour lifespan can reduce replacement frequency and associated material waste
- COB construction provides uniform illumination, supporting efficient use of light in architectural applications
- 24V DC operation enables use with efficient constant-voltage LED drivers
- LED components and aluminium heat sinks can be separated for recycling at end of service life
Domus Lighting warranty: residential COB LED strips receive 3 years replacement warranty, extending to a total 5 years when used with Domus drivers. Commercial applications receive 12 months replacement warranty, extending to a total 2 years when used with Domus drivers. Warranty eligibility requires installation by a licensed electrician and compliance with Domus installation guidelines.
Available through Domus Lighting and authorised Australian lighting distributors, subject to distributor stock availability.
