Plex-COB-5-IP67 LED Strip 24V IP67 CRI90 3000K 50m Roll Domus
Domus Plex-COB-5-IP67 LED Strip, 24V DC, IP67, CRI90, 640 LED/m, 3000K, 50m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: COB LED Tape, Dotless LED Strip, Waterproof LED Strip, 24V LED Strip Light, Warm White LED Tape
- Light Source: COB LED
- Input Voltage: 24V DC
- Power Consumption: 5W per metre
- Total Roll Power: 250W
- Luminous Output: 390lm per metre
- Colour Temperature: 3000K warm white
- Colour Rendering Index: ≥90
- LED Density: 640 LEDs per metre
- Beam Angle: 180°
- Ingress Protection: IP67
- Dimming: Yes, with compatible LED driver and dimmer
- Cutting Increment: 25mm
- Wiring: Parallel
- Continuous Run: Maximum 5m with one-end driver feed; 10m with two-end driver feed
- Service Life: Up to 50,000 hours
- Operating Temperature: -20°C to 50°C
- Required Driver: 24V DC constant-voltage LED driver
- Heat Management: Must be installed on an aluminium heat sink
- Dimensions (H x L x W): 4.5mm x 50000mm x 12mm
- Weight: 1.8 kg
- COB technology provides a smooth, dotless linear appearance
- IP67 silicone-coated construction for waterproof installations
- High CRI90 light quality for accurate colour rendering
- 24V DC operation helps reduce resistive heat over longer runs
- 3000K warm white light suitable for residential and commercial applications
- Dimmable with a suitable constant-voltage driver and control system
- Weldless joint design supports improved continuity and reliability
- 25mm cutting increments allow flexible length configuration
- Compatible with selected Domus PLEX-COB connectors and accessories
- Installation should be performed by a licensed electrician. Use a correctly sized 24V DC constant-voltage LED driver, provide suitable cable sizing and voltage-drop management, install the strip on an aluminium heat sink, and seal all IP67 connections and cut ends in accordance with the manufacturer's instructions and applicable wiring requirements.
- Architectural cove and feature lighting
- Kitchen, bathroom and laundry lighting
- Bar, restaurant and hospitality interiors
- Display, cabinet and joinery lighting
- Commercial linear lighting installations
- Outdoor or wet-area feature lighting where the complete installation maintains IP67 protection
- AS/NZS 60598.1:2017 - General safety and construction requirements for complete luminaires and lighting assemblies
- AS/NZS 60598.2.23:2021 - Extra-low-voltage lighting systems for ELV light sources
- AS/NZS 3000:2018 - Wiring Rules for the associated mains-connected driver and electrical installation
- LED technology provides efficient illumination at 5W per metre, helping reduce energy consumption compared with conventional light sources
- Long rated service life of up to 50,000 hours can reduce replacement frequency and material waste
- 24V DC operation supports efficient low-voltage lighting system design
- COB LED construction provides high light uniformity, reducing the need for multiple discrete light sources
Domus COB LED strips have a 3-year replacement warranty for residential applications and a 12-month replacement warranty for commercial applications. When used with Domus drivers, coverage may extend to 5 years residential or 2 years commercial. Warranty eligibility requires installation by a licensed electrician and compliance with Domus installation guidelines.
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting distributors.
Lighting Requirement Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
