Plex-COB-5-IP67 LED Strip 24V IP67 CRI90 5000K 20m Roll Domus
Domus Plex-COB-5-IP67 LED Strip, 24V DC, IP67, CRI90, 640 LED/m, 5000K, 20m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: COB LED Strip Light, Dotless LED Strip, IP67 Waterproof LED Tape, 24V LED Strip
- LED Type: COB, 640 LEDs per metre
- Input Voltage: 24V DC
- Power Consumption: 5W per metre; 100W per 20m roll
- Colour Temperature: 5000K
- Lumen Output: 425lm per metre; approximately 8,500lm per 20m roll
- Colour Rendering Index: CRI ≥90
- Beam Angle: 180°
- IP Rating: IP67
- Dimming: Yes, with suitable LED driver and dimmer
- Cutting Increment: 25mm
- Maximum Continuous Run: 5m with single-end feed; 10m with feed from both ends
- Rated Life: 50,000 hours
- Operating Temperature: -20°C to 50°C
- Storage Temperature: -30°C to 80°C
- Driver Requirement: 24V DC constant-voltage LED driver
- Heat Management: Must be installed on an aluminium heat sink or LED profile
- Wiring: Parallel
- Dimensions (H x L x W): 4.5mm x 20000mm x 12mm
- Weight: 1 kg
- COB technology produces a smooth, true dotless linear appearance
- IP67 silicone-coated construction for waterproof installations
- High CRI90 output for accurate colour rendering
- 5000K white colour temperature for crisp neutral illumination
- Dimmable with a compatible 24V LED driver and dimmer
- 25mm cutting increments for flexible sizing
- Weldless joint design improves continuity and reliability
- Suitable for kitchens, bathrooms, laundries, bars, restaurants and feature lighting
- Available as a 20m roll for longer linear lighting installations
- Installation of the 24V LED strip and associated mains-powered driver should be carried out by a licensed electrician in accordance with the manufacturer's installation instructions. The strip must be mounted on an aluminium heat sink or LED profile, and all IP67 cuts, joins and terminations must be suitably sealed. A 20m roll must be divided into runs within the specified maximum continuous-run lengths.
- Architectural and feature lighting
- Kitchen, bathroom and laundry lighting
- Bar and restaurant lighting
- Under-cabinet and joinery lighting
- Commercial display and hospitality lighting
- Cove, shelf and recessed linear lighting
- Water-resistant indoor and suitable protected outdoor lighting installations
- AS/NZS 60598.1 may apply to the complete luminaire or lighting assembly
- AS/NZS 60598.2.20 may apply where the completed installation is classified as a lighting chain
- The product-specific source material does not state a tested or certified AS/NZS compliance claim; verify the complete strip, driver, wiring and installation assembly before use
- Low 5W-per-metre power consumption can reduce energy use compared with higher-wattage linear lighting
- COB LED technology and approximately 50,000-hour rated life can reduce replacement frequency and material waste
- Dimmable operation allows light output and energy consumption to be reduced when full brightness is not required
- Aluminium heat-sink installation supports thermal management and longer product service life
Domus Lighting warranty: residential COB LED strips receive a 3-year replacement warranty, extending to a total 5-year replacement warranty when used with Domus drivers. Commercial applications receive a 12-month replacement warranty, extending to a total 2-year replacement warranty when used with Domus drivers. Warranty eligibility requires licensed-electrician installation and compliance with Domus installation guidelines.
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting distributors.
Lighting Requirement Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
