Plex-COB LED Strip Opposite Wiring Live Cable 500mm RGBTW Domus
Domus Plex-COB opposite-end wiring live cable with 500mm tail, rgbtw strip, pack of 5. Feeds power to the far end of an LED strip run.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: PLEX-COB RGBTW live cable, RGBTW LED strip far-end power feed cable, opposite-end wiring cable
Technical Specifications
- Accessory Type: Opposite-end wiring live cable
- Compatibility: Domus PLEX-COB RGBTW LED strip
- Cable Tail Length: 500mm
- Pack Quantity: 5 cables
- Strip Type: COB LED strip
- Connection Method: Tool-assisted clamp connection using pliers; no soldering required
- Nominal Accessory IP Rating: IP20
- Connector Pulling Force: 4.64kgf
- Installation: Designed to fit within compatible Domus LED profiles
- Power Feed Function: Far-end feed for extended LED strip runs
- Dimensions (H x L x W): 4.5mm x 500mm x 10mm
- Weight: 0.1 kg
Key Features
- Feeds power to the far end of an LED strip run
- Suitable for RGB plus tunable white PLEX-COB strip
- 500mm cable tail for remote connection routing
- Supplied as a five-piece pack
- Quick connection without soldering
- Designed for secure, reliable strip connections
- Connector design helps maintain continuous light without visible hotspots
- Compatible connectors fit inside the supplied Domus profile range
Professional Installation Requirements
- Connection to the 24V DC LED strip system should be completed by a licensed electrician or suitably qualified lighting installer in accordance with the strip, driver and controller installation instructions. Domus warranty eligibility requires installation by a licensed electrician.
Applications
- Far-end power injection for Domus PLEX-COB RGBTW LED strip
- Extended RGB plus tunable white LED strip runs
- Residential feature lighting
- Kitchen, wardrobe, shelving and pelmet lighting
- Commercial display, hospitality and interior architectural lighting
Standards & Compliance
- AS/NZS 3000: Electrical installations, applicable to the wiring and connection of the low-voltage lighting installation
Environmental Benefits
- Supports efficient LED lighting systems that use less energy than conventional lighting technologies
- Tool-assisted connection avoids soldering consumables during installation
- Modular replacement accessory can extend the service life of compatible LED strip installations and reduce replacement waste
Warranty Information
Domus Lighting standard warranty: 12-month replacement warranty for products not otherwise listed in the warranty schedule. Warranty conditions include licensed-electrician installation, approved purchase, correct installation and use with compatible products. Australian Consumer Law rights apply.
Available Now
Available through Domus Lighting and authorised Australian electrical wholesalers and lighting retailers.
