Plex-Ultra COB LED Strip 10W/m 24V IP67 2700K 50m Roll Domus
Domus Plex-Ultra COB LED Strip, 10W/m, 24V DC, IP67, CRI90, 560 LED/m, 2700K, 50m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Plex-Ultra IP67 LED Strip, Domus COB LED Tape, Dotless LED Strip, 24V Waterproof LED Strip
- Light Source: COB LED
- Colour Temperature: 2700K extra warm white
- Power: 10W per metre; 500W per 50m roll
- Input Voltage: 24V DC
- Lumen Output: 550 lm/m at 2700K
- Colour Rendering Index: CRI ≥90
- LED Density: 560 LEDs per metre
- Beam Angle: 180°
- Ingress Protection: IP67 with silicone coating
- Wiring: Parallel
- Cutting Increment: 25mm
- Maximum Continuous Run: 13m with single-end feed; 26m with feeds at both ends
- Dimming: Yes, with suitable dimmer and compatible driver
- Required Driver: 24V DC constant-voltage LED driver
- Heat Management: Must be installed on an aluminium heat sink
- Dimensions (H x L x W): 4.5mm x 50000mm x 12mm
- Weight: 2.5 kg
- Dotless COB appearance for continuous, even illumination
- 2700K extra-warm white light suitable for ambient and decorative applications
- IP67 silicone-coated construction for waterproof installations
- High CRI ≥90 for improved colour rendering
- 24V DC operation reduces resistive heat over longer runs
- 560 LEDs per metre for smooth linear light output
- 25mm cutting increments
- Dimmable with suitable control equipment
- Optional fast-fix and L-joint accessories available
- Installation should be performed by a licensed electrician. Use a correctly sized 24V DC constant-voltage LED driver, install the strip on an aluminium heat sink, and complete wiring in accordance with AS/NZS 3000. IP67 connectors, end caps and seals must be used where the installation requires maintained water protection.
- Kitchen benchtop and cabinet lighting
- Bathroom and laundry highlighting
- Bars, restaurants and hospitality interiors
- Commercial linear lighting projects
- Display, joinery and architectural feature lighting
- Waterproof indoor or protected outdoor accent lighting
- AS/NZS 3000:2018 Electrical installations — installation and wiring requirements for the connected lighting system
- AS/NZS 60598.1 may apply to the complete luminaire or lighting assembly
- AS/NZS 61347.2.13 may apply to the separate LED driver or controlgear; verify driver certification before installation
- LED technology provides efficient directional lighting with lower energy use than many conventional light sources
- 24V DC COB design reduces resistive heat and supports longer runs with fewer joins
- Long service life can reduce replacement frequency and material waste
- The required aluminium heat sink is durable and recyclable
- LED operation produces no ultraviolet or infrared radiation according to the Domus product literature
Domus warranty: 3-year replacement warranty for residential applications, or 12-month replacement warranty for commercial applications. When used with Domus drivers, COB LED strips receive a total 5-year replacement warranty residentially or 2 years commercially. Warranty requires licensed installation, adherence to installation instructions and installation on an aluminium heat sink.
Available through Domus Lighting and authorised Australian electrical and lighting distributors.
