Plex-Ultra COB LED Strip 10W/m 24V IP67 4000K 50m Roll Domus
Domus Plex-Ultra COB LED Strip, 10W/m, 24V DC, IP67, CRI90, 560 LED/m, 4000K, 50m roll. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Plex-Ultra IP67 COB LED Strip, 24V Waterproof LED Tape, High-CRI LED Strip Lighting
- Product Code: PLEX-ULTRA-IP67-50M, variant 24188
- Roll Length: 50 metres
- Wattage: 10W per metre
- Input Voltage: 24V DC
- Light Output: 669 lumens per metre at 4000K
- Colour Temperature: 4000K neutral white
- LED Type: COB LED
- LED Density: 560 LEDs per metre
- Colour Rendering Index: CRI ≥90
- Beam Angle: 180°
- Ingress Protection: IP67
- Wiring: Parallel
- Cutting Increment: 25mm
- Maximum Continuous Run: 13m with one-end driver feed; 26m with driver feeds at both ends
- Dimming: Yes, with a suitable LED driver and dimmer
- Driver Requirement: 24V DC constant-voltage LED driver
- Heat Management: Must be installed on an aluminium heat sink
- Dimensions (H x L x W): 4.5mm x 50000mm x 12mm
- Weight: 3.5 kg
- COB LED technology produces a continuous, dotless light appearance
- IP67 silicon-coated construction for waterproof installations
- 4000K neutral white light with high CRI90 colour rendering
- Designed for extended run lengths with reduced heat and resistance
- Weldless joint construction supports continuity and reliability
- 25mm cutting increments for installation flexibility
- Dimmable with compatible 24V LED driver and dimmer
- Optional fast-fix and L-joint connectors available
- 13m maximum run from one driver feed or 26m with feeds at both ends
- Installation should be performed by a licensed electrician. Use a compatible 24V DC constant-voltage LED driver, install the strip on an aluminium heat sink, and follow the manufacturer's installation instructions. The 50m roll must be divided into electrically suitable sections within the stated maximum continuous-run limits.
- Architectural and feature lighting
- Kitchen, bathroom and laundry lighting
- Bars, restaurants and hospitality interiors
- Display, cabinetry and joinery lighting
- Commercial and residential linear lighting
- Waterproof indoor and sheltered outdoor lighting installations
- AS/NZS 60598.1:2017 - general safety requirements applicable to complete luminaires and lighting assemblies
- AS 61347.2.13:2018 - applicable safety requirements for associated electronic LED controlgear and 24V constant-voltage drivers
- LED technology provides efficient illumination at 10W per metre compared with many conventional linear-lighting alternatives
- Long-run design can reduce the number of drivers, cable runs and electrical connection points required in suitable installations
- Long service life and robust IP67 construction can reduce replacement frequency and associated material waste
- LED lighting contains no mercury-based fluorescent lamp and supports lower operating energy consumption
Domus Lighting warranty: COB LED strips receive a 3-year replacement warranty for residential applications and a 12-month replacement warranty for commercial applications. When used with Domus drivers, total replacement warranty extends to 5 years residential or 2 years commercial. Warranty eligibility requires installation by a licensed electrician and compliance with installation guidelines, including use of an aluminium heat sink.
Available through Domus Lighting and authorised Australian distributors, subject to distributor stock availability.
Lighting Requirement Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
