Domus Plex-Vivid COB LED Strip, 15W/m, 24V DC, IP54, 640 LED/m, purple, sold per metre. Requires 24V DC LED driver.
Sign in
Please login to continue to your account.
Alternatively Known As: Plex-Vivid Purple LED Strip, Domus COB LED Tape, 24V Purple LED Strip, Vivid Purple LED Tape
- Variant: 24134
- Wattage: 15W per metre
- Input Voltage: 24V DC
- IP Rating: IP54; indoor use, including suitable wet areas
- Light Source: COB LED
- Colour: Vivid purple
- LED Density: 640 LEDs per metre
- Beam Angle: 180°
- Wiring: Parallel
- Cutting Increments: 25mm
- Maximum Continuous Run: 5m with one-end driver feed or 10m with feeds at both ends
- Dimming: Yes, with compatible control equipment
- Required Driver: 24V DC constant-voltage LED driver
- Operating Temperature: -20°C to 50°C
- Strip Width: 10mm
- Strip Height: 2.8mm
- Dimensions (H x L x W): 2.8mm x 1000mm x 10mm
- Weight: 0.1 kg
- True dotless COB appearance
- 640 LEDs per metre for continuous-looking illumination
- 24V DC operation designed to reduce resistive heat and support longer runs
- Dimmable with compatible controllers
- Can be cut every 25mm
- Suitable for indoor highlighting applications and wet-area use within its IP54 rating
- Must be installed on an aluminium heat sink in accordance with Domus requirements
- Optional connectors are available for straight, corner and flexible joins
- Installation should be completed by a licensed electrician, particularly where the 24V DC driver connects to mains power. Use a compatible 24V DC constant-voltage LED driver and install the strip on an aluminium heat sink; Domus states that failure to use an aluminium heat sink will void the warranty. ([domuslighting.com.au](https://www.domuslighting.com.au/wp-content/uploads/2025/08/PLEX-VIVID-IP67-Data-Sheet.pdf))
- Decorative kitchen and cabinetry lighting
- Bathroom and laundry highlighting within suitable IP54 installation conditions
- Bar, restaurant and hospitality feature lighting
- Retail displays, shelving and joinery illumination
- Indoor architectural and accent lighting
- AS/NZS 60598.2.23:2021 is applicable to extra-low-voltage lighting systems; compliance should be assessed for the complete strip, driver and installation assembly.
- AS/NZS 3000 applies to the associated electrical installation and mains connection of the LED driver.
- 24V LED operation is designed to reduce resistive heat, which may support efficient longer runs compared with higher-current low-voltage arrangements.
- Installation on an aluminium heat sink supports thermal management and may extend product service life, reducing replacement waste.
- LED technology provides targeted illumination with lower operating power than many conventional decorative lighting alternatives.
Domus warranty statement dated 9 January 2026 provides a 3-year replacement warranty for COB LED strips in residential applications, extended to a total of 5 years when used with Domus drivers. Commercial applications receive a 12-month replacement warranty, extended to a total of 2 years when used with Domus drivers. Warranty eligibility requires installation by a licensed electrician and adherence to installation guidelines, including aluminium heat-sink installation. ([domuslighting.com.au](https://www.domuslighting.com.au/wp-content/uploads/2026/01/Warranty-Statement-Revised-09-01-2026.pdf))
Available through Domus Lighting and authorised Australian electrical and lighting distributors. Supplied per metre; confirm current distributor stock before ordering.
Lighting Requirement Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
