Plinth for Marina Enclosures | IP66 & IK10 Rated | Fiberglass Reinforced | RAL 7035 Grey | @Each of 1 | by Legrand

BRAND: Legrand
SKU: 036296
$732.20 List price: $912.40
+
The Plinth for Marina Enclosures is designed for robust industrial applications, featuring IP66 and IK10 ratings for superior dust and water protection. Made from fiberglass reinforced polyester, it offers self-extinguishing properties and is ideal for corrosive environments. Perfect for electrical cabinets, this plinth ensures durability and safety in demanding conditions.

Product Name/Title: Plinth for Marina Enclosures | IP66 & IK10 Rated | Fiberglass Reinforced | RAL 7035 Grey | @Each of 1 | by Legrand

Brand: Legrand

SKU: 036296

Alternatively Known As: Marina Enclosure Base Plinth, Electrical Cabinet Plinth, Industrial Enclosure Base

Technical Specifications
  • Material: Fiberglass reinforced polyester
  • Protection rating: IP66 (IEC EN 60529)
  • Impact resistance: IK10 (EN 62262)
  • Class II insulation (EN 60439-1)
  • Self-extinguishing at 960°C (IEC EN 60695-2-11)
  • Suitable for enclosure width 800 mm and depth 400 mm
  • Includes fixing kit for plain plates or sectioned uprights
  • Equipped with low cable entry plate
  • 3-point locking handle with 1/2 locking latch 2433 A
  • Stainless steel hinges and hinge axis
  • Color: RAL 7035 Grey
  • Dimensions (H x L x W): 170mm x 380mm x 790mm
  • Weight: 10 kg
Key Features
  • Made of fiberglass reinforced polyester with self-extinguishing properties at 960°C
  • IP66 rated for dust and water ingress protection
  • IK10 rated for impact resistance
  • Class II insulation for totally isolated assemblies
  • Equipped with low cable entry plate and reversible door with strand-holder
  • 3-point closing handle with locking latch
  • Stainless steel hinges and hinge axis
  • Front and rear trap doors
  • Can overlap two plinths for height adjustment
  • Adapted to corrosive environments
Professional Installation Requirements
  • Installation should be performed by qualified personnel familiar with industrial enclosure assembly and electrical safety standards.
Applications
  • Industrial enclosures for electrical and electronic equipment
  • Suitable for corrosive environments requiring robust protection
  • Used in assembly of isolated electrical cabinets
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Durable materials reduce need for frequent replacements
  • Corrosion resistance extends product lifespan, minimizing waste
Warranty Information

Standard Legrand warranty applies; typically 2 years against manufacturing defects.

Available Now

The Legrand Plinth for Marina Enclosures - Height 170 mm is available for immediate purchase, ideal for industrial and commercial electrical enclosure applications.
