Plug-in Relay 24V AC/DC | 3A/5A/10A Rated Current | 2/4 Change-Over Contacts | Noark
Plug-in relay with 24V AC/DC operating voltage and rated current options of 3A, 5A, or 10A—ideal for industrial control systems and automation equipment. Built for reliable switching, featuring a locking button for secure installation and a status indicator for operational monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Ex9CH20 40 24V 50/60Hz
Brand: Noark
SKU: 102407
Alternatively Known As: Plug-in Relay Ex9JM, Ex9CH20 Relay, Noark Industrial Relay
Technical Specifications
- Rated current: 3A, 5A, or 10A
- Contact configuration: 2 change-over contacts (5A or 10A) or 4 change-over contacts (3A)
- Operating voltage: 24V AC/DC
- Frequency: 50/60Hz
- Locking button on plug for secure installation
- Status indicator included
- Dimensions (H x L x W): 85mm x 60mm x 35mm
- Weight: 0.1 kg
Key Features
- Meets requirements of IEC / EN 61810-1
- Rated current options: 3A, 5A, or 10A
- Available in versions with 2 change-over contacts (5A or 10A) and 4 change-over contacts (3A)
- Plugs and bases are sold separately
- Locking button on the plug for secure connection
- Status indicator for operational monitoring
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Industrial control systems
- Automation equipment
- Electrical installations requiring relay switching
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Compliant with IEC standards ensuring energy-efficient operation
- Durable design reduces replacement frequency and waste
Warranty Information
Standard manufacturer warranty applies; please refer to Noark for specific warranty terms.
Available Now
The Noark Plug-in Relay Ex9JM Ex9CH20 40 24V 50/60Hz is available for immediate purchase, ideal for industrial and electrical control applications.
