Pneumatic Timer Relay 180s | 346-440V AC | DIN Rail Mount | Screw Connection by NHP
Pneumatic timer relay with 180-second off delay and 346-440V AC supply—ideal for industrial automation and HVAC systems. Built for precise timing control, with easy screw connection and DIN rail mounting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CA7 Timer Pneumatic Off Delay 180s
Brand: NHP
SKU: CZA7180
Alternatively Known As: Pneumatic Timer Relay, Timer Relay CA7
Technical Specifications
- Voltage Type for Actuating: AC
- Rated Control Supply Voltage: 346-440 V at AC 50 Hz
- Number of Outputs: 1 delayed change-over contact
- Power Consumption: 0.5 VA
- Electrical Lifespan of Control Contacts: 200,000 cycles
- Mechanical Lifetime of Control Contacts: 30,000,000 cycles
- Operating Temperature: -25 to 45 °C
- Time Setting Accuracy: 5%
- Power Supply Reset Time: 50 ms
- Max Shock Acceleration: 50 g
- Max Vibration Acceleration: 4 m/s²
- Max Vibration Frequency Operational: 100 Hz
- Dimensions (H x L x W): 80mm x 109mm x 22.5mm
- Weight: 0.5 kg
Key Features
- Pneumatic timer with a delay of 180 seconds.
- Screw connection for easy installation.
- Suitable for DIN rail mounting.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems requiring precise timing control
- Commercial: HVAC systems for delay functions
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Efficient power consumption reduces energy waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CA7 Timer Pneumatic Off Delay 180s is available now for immediate purchase. Ideal for industrial and commercial applications requiring precise timing control.
