Point I/O 4AI Module | 16-Bit Resolution | 4 Analogue Inputs | 24V DC by NHP
Point I/O module with 16-bit resolution and 4 analogue inputs—ideal for industrial automation and process control. Built for precision, with 24V DC supply and wide temperature range operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley Point I/O 4AI High Density Current Module
Brand: NHP
SKU: 1734IE4C
Alternatively Known As: Point I/O Module, High Density Current Module, 4AI Module
Technical Specifications
- Type of Voltage Input: DC
- Resolution of the Analogue Inputs: 16 Bit
- Supply Voltage DC: 24-24 V
- Number of Analogue Inputs: 4
- Operating Temperature: -20-55 °C
- Storage Temperature: -40-85 °C
- Max Ambient Humidity Non-Condensing: 95%
- Dimensions (H x L x W): 56mm x 75.5mm x 12mm
- Weight: 0.5 kg
Key Features
- High density with 4 analogue inputs
- 16-bit resolution for precise measurements
- Configurable analogue input signal
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial automation systems
- Process control applications
- Data acquisition systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Designed to operate in a wide temperature range, reducing the need for additional climate control.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley Point I/O 4AI High Density Current Module is available now for immediate purchase. Ideal for industrial automation and process control applications.
