Polyester Braid Sleeve 3-7mm | Durable & Flexible | Heat Resistant | 100m Length by Cabac
Exp. polyester braid sleeve in a 3-7mm size range, perfect for protecting cables and wires. Built for durability and flexibility, this 100m length is ideal for various applications, ensuring long-lasting performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Exp. Polyester Braid Sleeve | 3-7mm | Durable Protection | 100m Length by Unbranded
Brand: Cabac
SKU: EPBS4
Alternatively Known As: Polyester Braided Cable Sleeve, Expandable Cable Sleeve, Cable Management Sleeve, Heat Resistant Cable Sleeve, Protective Cable Braid
Technical Specifications
- Material: Monofilament Polyester
- Nominal Internal Diameter: 4mm
- Minimum Internal Diameter: 3mm
- Maximum Internal Diameter: 7mm
- Expansion Ratio: 1:2
- Monofilament Diameter: 0.22mm
- Reel Length: 100m
- Operating Temperature Range: -50 to +150 degrees Celsius
- Flammability: Self-extinguishing
- Chemical Resistance: Resistant to most aggressive chemicals
- Conformant Standards: IEC684-349, UL224
- Dimensions (H x L x W): 40mm x 100000mm x 7000mm
- Weight: 0.5 kg
Key Features
- Highly flexible polyester braided sleeving
- Expandable internal diameter from 3mm to 7mm
- Contracts in length while expanding diameter
- Mechanical protection against wear and abrasion
- Resistant to most aggressive chemicals
- Heat resistant and self-extinguishing
- Allows individual wire breakouts along the harness
Professional Installation Requirements
- No special professional installation required; easy to install by hand for bundling cables and wires.
Applications
- Cable management for bundling loose cables and wires
- Protective cable harness for electrical and electronic wiring
- Industrial and commercial wiring protection
- Automotive and machinery wiring protection
Standards & Compliance
- AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable and reusable cable protection reduces cable waste
- Heat resistant properties improve cable lifespan, reducing replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to Cabac warranty policy for details.
Available Now
The Cabac Exp.Polyester Braid Sleeve 3-7mm 100m is available now for immediate purchase. Ideal for cable management in industrial, commercial, and residential applications.
