Post Base Plate | Hot Dipped Galvanised | 14mm Holes
Post base plate with hot dipped galvanised finish and 14mm diameter holes—ideal for structural support. Built for durability, with 40mm width and 6mm thickness for robust applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Post Base Plate | Hot Dipped Galvanised | 14mm Holes
SKU: P2072S1H
Alternatively Known As: Post Mounting Plate, Galvanised Base Plate, Steel Post Base, Hot Dip Galvanised Post Support
Technical Specifications
- Material: Punch press formed plate steel
- Finish: Hot dipped galvanised to AS/NZS 4680
- Hole Diameter: 14mm
- Hole Spacing: 21mm from end, 48mm on centre
- Thickness: 6mm
- Width: 40mm
- Mass: 62 kg per 100 units
- Dimensions (H x L x W): n/a mm x n/a mm x 40mm
- Weight: 0.62 kg
Key Features
- Hot dipped galvanised finish to AS/NZS 4680 for superior corrosion resistance
- 14mm diameter holes compatible with M12 x 24 hex head set screws and M12 nuts
- 6mm thick steel plate for robust structural support
- Hole spacing: 21mm from end and 48mm on centre
- Width of 40mm for stable base mounting
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with structural fittings and fastening techniques to ensure safety and compliance.
Applications
- Structural support for posts in construction and building projects
- Suitable for use with 41mm square members and various channel fittings
- Ideal for outdoor and industrial applications requiring corrosion resistance
Standards & Compliance
- Complies with AS/NZS 4680 – Hot Dip Galvanized Coatings on Fabricated Ferrous Articles
Environmental Benefits
- Hot dipped galvanising provides long-lasting corrosion protection, reducing the need for frequent replacements and minimizing waste.
Warranty Information
Warranty details available upon request; typically includes protection against manufacturing defects.
Available Now
The Post Base Plate Hot Dipped Galvanised with 14mm Holes is available now for immediate purchase. Ideal for construction and structural support applications requiring durable and corrosion-resistant fittings.
