Power Contactor TeSys F LC1F 3P AC3 | 800A Rated Current | High Electrical Durability | by Clipsal
The Power Contactor TeSys F LC1F 3P AC3 is designed for industrial motor control, featuring a robust 800A rated operational current at 440V AC-3. Ideal for heavy-duty machinery and HVAC systems, this contactor ensures high electrical durability with up to 1 million cycles, making it perfect for demanding environments. Professional installation is recommended to comply with local electrical standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Power Contactor TeSys F LC1F 3P AC3 | 800A Rated Current | High Electrical Durability | by Clipsal
Brand: Clipsal
SKU: SCHLC1F800QW
Alternatively Known As: TeSys F Contactor, LC1F800QW, Schneider 3P Contactor, 800A AC3 Contactor, Industrial Power Contactor
Technical Specifications
- Type: Power Contactor
- Series: TeSys F
- Poles: 3P (3NO)
- Utilization Category: AC-3
- Rated Operational Current: 800A (at 440V AC-3)
- Coil Voltage: 380...415V AC / 400V DC
- Rated Insulation Voltage: 1000V
- Conventional Thermal Current: 1000A
- Electrical Durability: 1 million cycles (AC-3)
- Mechanical Durability: 5 million cycles
- Mounting: Panel
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 330mm x 220mm x 320mm
- Weight: 18 kg
Key Features
- 3-pole (3NO) power contactor for AC-3 applications
- Rated operational current: 800A at 440V AC-3
- Coil voltage: 380...415V AC / 400V DC
- High electrical durability for frequent switching
- Robust design for demanding industrial environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial motor control
- Heavy-duty machinery
- Pumping stations
- HVAC systems
- Power distribution panels
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Enables efficient energy management in industrial systems
- Supports reliable operation, reducing downtime and waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Schneider Electric TeSys F LC1F800QW 3P AC3 800A Contactor is available for immediate purchase. Ideal for industrial motor control and heavy-duty power distribution applications.
