Power Coupling Connect 3P Interlocked | 32A Rated Current | IP66 Weatherproof | @Pack of 1 | by Clipsal
Power Coupling Connect 3P Interlocked is designed for secure power connections in industrial settings, featuring a robust 32A rated current and IP66 weatherproof rating. Ideal for commercial buildings and construction sites, this outlet ensures safety with its interlocked circuit breakers, preventing accidental disconnection under load.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Power Coupling Connect 3P Interlocked | 32A Rated Current | IP66 Weatherproof | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCH29358
Alternatively Known As: Clipsal Interlocked Socket, 3 Phase Interlocked Outlet, Industrial Power Outlet, Clipsal SCH29358, 3P Interlock Socket
Technical Specifications
- Rated Voltage: 415V AC
- Rated Current: 32A
- Poles: 3P+E
- Interlocked with 2 circuit breakers
- IP66 weatherproof rating
- Material: High-impact resistant plastic
- Mounting: Surface mount
- Operating Temperature: -25°C to +55°C
- Dimensions (H x L x W): 300mm x 180mm x 120mm
- Weight: 2.5 kg
Key Features
- Three-phase power coupling with interlocked circuit breakers for enhanced safety
- Robust construction suitable for demanding industrial environments
- Interlock mechanism prevents accidental disconnection under load
- Easy installation and maintenance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local regulations and standards.
Applications
- Industrial facilities requiring secure power connections
- Commercial buildings with heavy-duty electrical equipment
- Construction sites for temporary or permanent power distribution
- Warehouses and manufacturing plants
Standards & Compliance
- Complies with AS/NZS 3123 – Industrial Plugs and Socket-Outlets
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Reliable connections minimize energy loss and improve operational efficiency
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Power Coupling Connect 3P 2 CB Interlocked SCH29358 is available for immediate purchase. Ideal for industrial and commercial power distribution applications.
