POWERTAG WISER P63 1PN TOP RCBO | 63A Rated Current | Zigbee Wireless | IP20 Rated | @Pack of 1 | by Clipsal
The POWERTAG WISER P63 1PN TOP RCBO is a smart circuit breaker that combines RCD and MCB functions, providing 63A rated current and Zigbee wireless communication for real-time energy monitoring. Ideal for residential, commercial, and light industrial applications, it ensures protection against earth leakage and overload while enabling efficient energy management.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: POWERTAG WISER P63 1PN TOP RCBO | 63A Rated Current | Zigbee Wireless | IP20 Rated | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: CLI4RCBEM2T
Alternatively Known As: Clipsal PowerTag RCBO, Wiser Energy RCBO, Smart RCBO, CLI4RCBEM2T, Clipsal Smart Circuit Breaker
Technical Specifications
- Rated current: 63A
- Poles: 1P+N (Single Phase + Neutral)
- Rated voltage: 230V AC
- Breaking capacity: 6kA
- Earth leakage sensitivity: 30mA
- Wireless communication: Zigbee (for Wiser Energy integration)
- Mounting: DIN rail
- Operating temperature: -25°C to +60°C
- IP rating: IP20 (when installed in enclosure)
- Dimensions (H x L x W): 90mm x 75mm x 18mm
- Weight: 0.25 kg
Key Features
- Combines residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Enables real-time energy monitoring and remote control via Wiser Energy system
- Wireless communication for integration with smart home and building management systems
- Provides protection against earth leakage, overload, and short circuit faults
- Compact DIN rail mount design for easy installation
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with Australian standards and local regulations.
Applications
- Residential: Smart homes, apartments, and townhouses
- Commercial: Offices, retail spaces, and small businesses
- Industrial: Light industrial facilities requiring advanced circuit protection and energy monitoring
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009 – Residual current operated circuit-breakers with integral overcurrent protection
Environmental Benefits
- Enables energy monitoring to help reduce power consumption
- Supports smart automation for efficient energy management
- Reduces electrical waste by combining RCD and MCB functions in one device
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal POWERTAG WISER P63 1PN TOP RCBO CLI4RCBEM2T is available for immediate purchase. Ideal for smart homes, commercial, and light industrial applications requiring advanced circuit protection and energy monitoring.
