Pressure Sensor | Compound Pressure Measurement | IP67 Rated | High Accuracy | by SICK
The Pressure Sensor is designed for precise compound pressure measurement, featuring a measuring range of -1 bar to 1.5 bar and an impressive accuracy of ≤ ±0.5% span. Ideal for industrial process control, it supports both liquid and gaseous media, ensuring reliable performance in hydraulic and pneumatic systems. With a robust stainless steel housing and IP67 rating, this sensor is built to withstand harsh environments while providing fast response times under 4 ms.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pressure Sensor | Compound Pressure Measurement | IP67 Rated | High Accuracy | by SICK
Brand: SICK
SKU: 6076653
Alternatively Known As: Compound Pressure Sensor, Industrial Pressure Transmitter, 4-20mA Pressure Sensor, Stainless Steel Pressure Sensor
Technical Specifications
- Measuring range: -1 bar to 1.5 bar
- Pressure type: Compound pressure
- Medium: Liquid and gaseous
- Process temperature range: -30 °C to +100 °C
- Output signal: 4 mA to 20 mA, 2-wire
- Supply voltage: 8 V DC to 30 V DC
- Power consumption: Max 25 mA for current output
- Process connection: G ½ B (EN 837)
- Wetted parts: 316L stainless steel
- Internal transmission fluid: Silicone oil (for certain pressure ranges)
- Electrical safety: Overvoltage protection 32-36 V DC, short-circuit and reverse polarity protection
- Enclosure rating: IP67
- Response time: < 4 ms
- Accuracy: ≤ ±0.5% of span
- Non-linearity: ≤ ±0.25% of span
- Hysteresis: ≤ 0.16% of span
- Non-repeatability: ≤ 0.1% of span
- Long-term drift: ≤ 0.1% of span per year
- Operating ambient temperature: 0 °C to +80 °C
- Storage temperature: -40 °C to +70 °C
- Shock load: 500 g
- Vibration load: 10 g standard, 20 g optional
- Dimensions (H x L x W): 70mm x 30mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 1.5 bar
- Suitable for liquid and gaseous media
- High accuracy with ≤ ±0.5% span error including non-linearity and hysteresis
- Fast response time under 4 ms
- Robust stainless steel housing and wetted parts (316L stainless steel)
- IP67 rated enclosure for dust and water protection
- Overvoltage, short-circuit, and reverse polarity protection
- Long service life with minimum 100 million load cycles
- Output signal: 4 mA to 20 mA, 2-wire
- Wide supply voltage range from 8 V DC to 30 V DC
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and process instrumentation to ensure safety and compliance with local regulations.
Applications
- Industrial process control for liquid and gaseous media
- Hydraulic and pneumatic systems monitoring
- Pressure measurement in manufacturing and automation
- Environmental monitoring requiring compound pressure sensing
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life
- Low power consumption enhances energy efficiency
- High reliability minimizes replacement frequency and electronic waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK PBT-CB2X5AGESECAMA0Z Pressure Sensor is available for immediate purchase, ideal for industrial and process control applications requiring reliable compound pressure measurement.
