Pressure Sensor PBT-RB1X0SGTSSNAMA0Z | Gauge Pressure Measurement | IP67 Rated | Stainless Steel Housing | by SICK
The PBT-RB1X0SGTSSNAMA0Z pressure sensor excels in gauge pressure measurement for both liquid and gaseous media, featuring a measuring range of 0 bar to 1 bar. With a robust stainless steel housing and an IP67 enclosure rating, it’s perfect for industrial process control and automation systems. Designed for high accuracy and fast response times, this sensor is ideal for hydraulic and pneumatic applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pressure Sensor PBT-RB1X0SGTSSNAMA0Z | Gauge Pressure Measurement | IP67 Rated | Stainless Steel Housing | by SICK
Brand: SICK
SKU: 6044093
Alternatively Known As: Gauge Pressure Sensor, Industrial Pressure Transmitter, 4-20mA Pressure Sensor, Stainless Steel Pressure Sensor
Technical Specifications
- Medium: Liquid, gaseous
- Pressure type: Gauge pressure
- Measuring range: 0 bar to 1 bar
- Process temperature: 0 °C to +80 °C
- Maximum ohmic load RA: 4 mA to 20 mA, 2-wire (RA ≤ (L + - 8 V) / 0.02 A [Ohm])
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ A (ISO 1179-2)
- Wetted parts: Stainless steel 316L
- Internal transmission fluid: Silicone oil (for certain pressure ranges)
- Housing material: Stainless steel
- Connection type: M12 round connector, 4-pin
- Supply voltage: 8 V DC to 30 V DC
- Power consumption: Max 25 mA for current output, max 8 mA for voltage output
- Electrical safety: Overvoltage protection 32 V DC / 36 V DC, short-circuit and reverse polarity protection
- Isolation voltage: 500 V DC
- Enclosure rating: IP67
- Accuracy: ≤ ±1% of span including non-linearity, hysteresis, zero point and full scale error
- Response time: < 4 ms
- Long-term drift: ≤ 0.1% of span per year
- Operating ambient temperature: 0 °C to +80 °C
- Storage temperature: -40 °C to +70 °C
- Shock load: 500 g
- Vibration load: 10 g (20 g optional)
- Dimensions (H x L x W): 80mm x 100mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures gauge pressure in liquid and gaseous media
- Measuring range from 0 bar to 1 bar
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ A (ISO 1179-2)
- Wetted parts made of stainless steel 316L
- Housing made of stainless steel with IP67 enclosure rating
- Overvoltage, short-circuit, and reverse polarity protection
- High accuracy with ≤ ±1% of span including non-linearity and hysteresis
- Fast response time under 4 ms
- Long service life with minimum 100 million load cycles
- Operating temperature range 0 °C to +80 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and calibration according to industrial standards.
Applications
- Industrial process control for liquid and gaseous media
- Pressure monitoring in hydraulic and pneumatic systems
- Automation systems requiring precise gauge pressure measurement
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life
- Low power consumption with efficient 4 mA to 20 mA output signal
- Complies with RoHS directive limiting hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK PBT-RB1X0SGTSSNAMA0Z pressure sensor is available for immediate purchase, ideal for industrial and automation applications requiring reliable gauge pressure measurement.
