Pressure Sensor | Gauge Pressure Measurement | Stainless Steel | IP67 Rated | by SICK
The Pressure Sensor is designed for precise gauge pressure measurement in liquid and gaseous media, featuring a measuring range of 0 bar to 0.1 bar. Built with durable stainless steel and an IP67 enclosure rating, it ensures reliable performance in industrial process control applications. With a fast response time under 4 ms and high accuracy of ≤ ±1% of span, this sensor is perfect for environments requiring robust pressure sensing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pressure Sensor | Gauge Pressure Measurement | Stainless Steel | IP67 Rated | by SICK
Brand: SICK
SKU: 6077444
Alternatively Known As: Gauge Pressure Sensor, Industrial Pressure Transmitter, 4-20mA Pressure Sensor, Stainless Steel Pressure Sensor
Technical Specifications
- Medium: Liquid, gaseous
- Pressure type: Gauge pressure
- Measuring range: 0 bar to 0.1 bar
- Process temperature range: –30 °C to +100 °C
- Maximum ohmic load RA: 4 mA to 20 mA, 2-wire (RA ≤ (L + - 8 V) / 0.02 A [Ohm])
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ B (EN 837)
- Wetted parts: Stainless steel 316L
- Internal transmission fluid: Silicone oil (for certain pressure ranges)
- Housing material: Stainless steel
- Connection type: M12 round connector, 4-pin
- Supply voltage: 8 V DC to 30 V DC
- Power consumption: Max 25 mA for current output, max 8 mA for voltage output
- Electrical safety: Overvoltage protection 32 V DC / 36 V DC, short-circuit and reverse polarity protection
- Isolation voltage: 500 V DC
- Enclosure rating: IP67
- Accuracy: ≤ ±1% of span including non-linearity, hysteresis, zero point and full scale error
- Response time: < 4 ms
- Long-term drift: ≤ 0.1% of span per year
- Operating ambient temperature: 0 °C to +80 °C
- Storage temperature: –40 °C to +70 °C
- Shock load: 500 g per IEC 60068-2-27
- Vibration load: 10 g per IEC 60068-2-6, 20 g optional
- Dimensions (H x L x W): 80mm x 100mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures gauge pressure in liquid and gaseous media
- Measuring range from 0 bar to 0.1 bar
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ B (EN 837)
- Wetted parts made of stainless steel 316L
- Housing made of stainless steel with IP67 enclosure rating
- Overvoltage, short-circuit, and reverse polarity protection
- High accuracy with ≤ ±1% of span including non-linearity and hysteresis
- Fast response time under 4 ms
- Long service life with minimum 100 million load cycles
- Operating temperature range 0 °C to +80 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical safety standards.
Applications
- Measurement of liquid and gaseous media pressure
- Industrial process control requiring gauge pressure monitoring
- Environments requiring robust and precise pressure sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life
- Low power consumption with efficient 4 mA to 20 mA output signal
- Compliant with RoHS directive limiting hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK PBT-RBX10SGESECAMA0Z pressure sensor is available for immediate purchase, ideal for industrial and process control applications requiring precise gauge pressure measurement.
