Pressure Sensor PBT-CB010AG2SE0AMA0Z | -1 to 9 Bar Range | IP67 Rated | High Accuracy | by SICK
The PBT-CB010AG2SE0AMA0Z pressure sensor is designed for precise compound pressure measurement, featuring a measuring range from -1 bar to 9 bar and high accuracy of ≤ ±0.5% span. Ideal for industrial process control and automation systems, it is built with robust stainless steel housing and offers IP67 protection, ensuring durability in harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pressure Sensor PBT-CB010AG2SE0AMA0Z | -1 to 9 Bar Range | IP67 Rated | High Accuracy | by SICK
Brand: SICK
SKU: 6042675
Alternatively Known As: Compound Pressure Sensor, Industrial Pressure Transmitter, Stainless Steel Pressure Sensor, 4-20mA Pressure Sensor
Technical Specifications
- Measuring range: -1 bar to 9 bar
- Pressure type: Compound pressure
- Medium: Liquid and gaseous
- Process temperature range: -30°C to +100°C
- Output signal: 4 mA to 20 mA, 2-wire
- Supply voltage: 8 V DC to 30 V DC
- Process connection: G ¼ female (EN 837)
- Wetted parts: 316L stainless steel
- Enclosure rating: IP67
- Electrical safety: Overvoltage protection 32-36 V DC, short-circuit and reverse polarity protection
- Response time: <4 ms
- Accuracy: ≤ ±0.5% of span
- Non-linearity: ≤ ±0.25% BFSL
- Hysteresis: ≤ 0.16% of span
- Non-repeatability: ≤ 0.1% of span
- Long-term drift: ≤ 0.1% of span per year
- MTTF: 815 years
- Connection type: M12 round connector, 4-pin
- Dimensions (H x L x W): 60mm x 60mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 9 bar
- Suitable for liquid and gaseous media
- High accuracy with ≤ ±0.5% span including non-linearity and hysteresis
- Fast response time under 4 ms
- Robust stainless steel housing with IP67 protection
- Overvoltage, short-circuit, and reverse polarity protection
- Long service life with minimum 100 million load cycles
- Integrated pressure peak dampening for stable readings
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical safety standards.
Applications
- Industrial process control for liquid and gaseous media
- Pressure monitoring in hydraulic and pneumatic systems
- Automation systems requiring precise compound pressure measurement
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces waste and replacement frequency
- Low power consumption enhances energy efficiency
- Long service life minimizes environmental impact from disposal
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK PBT-CB010AG2SE0AMA0Z pressure sensor is available for immediate purchase, ideal for industrial and automation applications requiring reliable compound pressure measurement.
