Pressure Sensor PBT-CB016SGTSSNAMA0Z | -1 to 15 Bar Range | IP67 Rated | High Accuracy | by SICK
The PBT-CB016SGTSSNAMA0Z pressure sensor measures compound pressure from -1 bar to 15 bar, making it ideal for industrial process control of both liquid and gaseous media. With a robust 316L stainless steel housing and an IP67 rated enclosure, it ensures durability and reliability in harsh environments. Experience high accuracy with ≤ ±1% of span and a fast response time under 4 ms, perfect for hydraulic and pneumatic systems monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pressure Sensor PBT-CB016SGTSSNAMA0Z | -1 to 15 Bar Range | IP67 Rated | High Accuracy | by SICK
Brand: SICK
SKU: 6070614
Alternatively Known As: Compound Pressure Sensor, Industrial Pressure Transmitter, Stainless Steel Pressure Sensor, 4-20mA Pressure Sensor
Technical Specifications
- Measuring range: -1 bar to 15 bar
- Pressure type: Compound pressure
- Medium: Liquid and gaseous
- Output signal: 4 mA to 20 mA, 2-wire
- Supply voltage: 8 V DC to 30 V DC
- Process connection: G ½ A (ISO 1179-2)
- Wetted parts: 316L stainless steel
- Internal transmission fluid: Silicone oil (for specific pressure ranges)
- Electrical safety: Overvoltage protection 32-36 V DC, short-circuit and reverse polarity protection
- Enclosure rating: IP67
- Accuracy: ≤ ±1% of span
- Response time: < 4 ms
- Temperature range: 0 °C to +80 °C (operation), -40 °C to +70 °C (storage)
- Shock load: 500 g IEC 60068-2-27
- Vibration load: 10 g IEC 60068-2-6 (20 g optional)
- MTTF: 815 years
- Service life: Minimum 100 million load cycles
- Dimensions (H x L x W): 70mm x 30mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 15 bar
- Suitable for liquid and gaseous media
- High accuracy with ≤ ±1% of span
- Robust stainless steel housing and wetted parts (316L stainless steel)
- IP67 rated enclosure for dust and water protection
- Overvoltage, short-circuit, and reverse polarity protection
- Fast response time under 4 ms
- Long service life with minimum 100 million load cycles
- Integrated pressure peak dampening for stable readings
- M12 round connector, 4-pin connection
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection and calibration according to industrial standards.
Applications
- Industrial process control for liquid and gaseous media
- Hydraulic and pneumatic systems monitoring
- Pressure measurement in manufacturing and automation
- Safety and monitoring in chemical and food industries
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable stainless steel construction reduces waste and replacement frequency
- Low power consumption enhances energy efficiency
- Long service life minimizes environmental impact from disposal
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK PBT-CB016SGTSSNAMA0Z pressure sensor is available for immediate purchase, ideal for industrial and process control applications requiring reliable compound pressure measurement.
