Pressure Sensor PBT-CB4X0SGESFSVLC0Z | -1 to 3 Bar Range | IP65 Rated | High Accuracy | by SICK
The PBT-CB4X0SGESFSVLC0Z pressure sensor measures compound pressure from -1 bar to 3 bar, making it ideal for industrial process control of liquid and gaseous media. With a robust stainless steel housing and an IP65 enclosure rating, it ensures durability and reliability in demanding environments. Its fast response time under 4 ms and high accuracy of ≤ ±1% span make it perfect for automation systems requiring precise pressure measurement.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pressure Sensor PBT-CB4X0SGESFSVLC0Z | -1 to 3 Bar Range | IP65 Rated | High Accuracy | by SICK
Brand: SICK
SKU: 6090464
Alternatively Known As: Compound Pressure Sensor, Industrial Pressure Transmitter, SICK Pressure Sensor PBT-CB4X0SGESFSFSVLC0Z
Technical Specifications
- Measuring range: -1 bar to 3 bar
- Pressure type: Compound pressure
- Medium: Liquid and gaseous
- Process temperature range: -20 °C to +100 °C
- Output signal: 0 V ... 10 V (3-wire), 4 mA ... 20 mA (2-wire)
- Supply voltage: 14 V DC to 30 V DC
- Power consumption: Max 25 mA for current output, max 8 mA for voltage output
- Electrical safety: Overvoltage protection 32 V DC, short-circuit and reverse polarity protection
- Enclosure rating: IP65
- Material: Stainless steel 316L wetted parts and housing
- Process connection: G ½ B (EN 837)
- Response time: < 4 ms
- Accuracy: ≤ ±1% of span including non-linearity and hysteresis
- Non-linearity: ≤ ±0.5% of span
- Hysteresis: ≤ 0.16% of span
- Non-repeatability: ≤ 0.1% of span
- Long-term drift: ≤ 0.1% of span per year
- Operating ambient temperature: 0 °C to +80 °C
- Storage temperature: -40 °C to +70 °C
- Shock load: 500 g IEC 60068-2-27
- Vibration load: 10 g IEC 60068-2-6 (20 g optional)
- MTTF: 1,176 years
- Dimensions (H x L x W): 80mm x 100mm x 40mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 3 bar
- Suitable for liquid and gaseous media
- Output signal options: 0 V ... 10 V, 3-wire; 4 mA ... 20 mA, 2-wire
- Process connection G ½ B (EN 837) with stainless steel wetted parts
- High accuracy with ≤ ±1% span including non-linearity and hysteresis
- Fast response time under 4 ms
- Robust stainless steel housing with IP65 enclosure rating
- Overvoltage, short-circuit, and reverse polarity protection
- Long service life with minimum 100 million load cycles
- CE conformity with Pressure Equipment Directive 2014/68/EU and EMC Directive 2014/30/EU
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial process control for liquid and gaseous media
- Pressure monitoring in hydraulic and pneumatic systems
- Automation systems requiring precise compound pressure measurement
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life
- Low power consumption enhances energy efficiency in industrial applications
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK PBT-CB4X0SGESFSFSVLC0Z pressure sensor is available for immediate purchase, ideal for industrial and automation applications requiring reliable compound pressure measurement.
