Pressure Transmitter PBT-RB4X0SGESESALA0Z | 0-4 Bar Gauge Pressure | IP65 Rated | Stainless Steel | by SICK
The Pressure Transmitter PBT-RB4X0SGESESALA0Z measures gauge pressure from 0 to 4 bar, making it ideal for industrial process control of liquid and gaseous media. With a robust stainless steel construction and an IP65 rated enclosure, it ensures durability and protection against dust and water. Designed for high accuracy and fast response time, this sensor is perfect for manufacturing and automation systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 70mm x 50mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures gauge pressure from 0 to 4 bar
- Suitable for liquid and gaseous media
- Process temperature range from -30 °C to +100 °C
- Output signal: 4 mA to 20 mA, 2-wire
- Stainless steel 316L wetted parts and housing
- IP65 rated enclosure for dust and water protection
- Overvoltage, short-circuit, and reverse polarity protection
- Fast response time under 4 ms
- High accuracy with ≤ ±1% span including non-linearity and hysteresis
- Long service life with minimum 100 million load cycles
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper connection and calibration.
Applications
- Industrial process control for liquid and gaseous media
- Pressure monitoring in manufacturing and automation systems
- Use in environments requiring gauge pressure measurement
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction extends product life reducing waste
- Low power consumption minimizes energy use
- High accuracy reduces process waste and improves efficiency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for details.
Available Now
The SICK PBT-RB4X0SGESESALA0Z pressure sensor is available for immediate purchase, ideal for industrial and process control applications.
