Pressure Transmitter PBT-RB400SGESECALA0Z | 0-400 Bar Measurement | IP65 Rated | Stainless Steel Durability | by SICK
The PBT-RB400SGESECALA0Z pressure transmitter measures gauge pressure from 0 to 400 bar, making it ideal for industrial process control of both liquid and gaseous media. With a robust stainless steel 316L construction and an IP65 rated enclosure, it ensures durability and reliability in harsh environments. This sensor features a 4-20mA output signal and high accuracy, perfect for hydraulic and pneumatic systems monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 70mm x 100mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures gauge pressure from 0 to 400 bar
- Suitable for liquid and gaseous media
- Stainless steel 316L wetted parts and housing for durability
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ B (EN 837)
- Operating temperature range: -30 °C to +100 °C
- Electrical safety features including overvoltage, short-circuit, and reverse polarity protection
- IP65 rated enclosure for dust and water resistance
- High accuracy with ≤ ±1% span including non-linearity and hysteresis
- Fast response time under 4 ms
- Long service life with minimum 100 million load cycles
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper connection and calibration according to industrial standards.
Applications
- Industrial process control for liquid and gaseous media
- Hydraulic and pneumatic systems monitoring
- Pressure measurement in manufacturing and automation
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces waste and replacement frequency
- Low power consumption with efficient 2-wire 4-20 mA output
- Complies with RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK PBT-RB400SGESECALA0Z pressure sensor is available for immediate purchase, ideal for industrial and automation applications requiring reliable pressure measurement.
