Pressure Transmitter PBT-CB016SG2SS0ALA0Z | Measures -1 to 15 Bar | IP65 Rated | Fast Response Time | by SICK
The Pressure Transmitter PBT-CB016SG2SS0ALA0Z is designed for accurate measurement of liquid and gaseous media pressure, with a range of -1 bar to 15 bar. Built for industrial process control, it features a fast response time under 4 ms and high accuracy of ≤ ±1% of span. Its durable stainless steel construction and IP65 enclosure make it ideal for demanding environments, ensuring long service life and reliability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Medium: Liquid, gaseous
- Pressure type: Compound pressure
- Measuring range: -1 bar to 15 bar
- Process temperature range: 0°C to +80°C
- Output signal: 4 mA to 20 mA, 2-wire
- Supply voltage: 8 V DC to 30 V DC
- Power consumption: Max 25 mA for current output, max 8 mA for voltage output
- Electrical safety: Overvoltage protection 32-36 V DC, short-circuit and reverse polarity protection
- Isolation voltage: 500 V DC
- Enclosure rating: IP65
- Response time: < 4 ms
- Accuracy: ≤ ±1% of span
- Non-linearity: ≤ ±0.5% BFSL
- Hysteresis: ≤ 0.16% of span
- Non-repeatability: ≤ 0.1% of span
- Long-term drift: ≤ 0.1% of span per year
- Shock load: 500 g IEC 60068-2-27
- Vibration load: 10 g IEC 60068-2-6, optional 20 g
- Dimensions (H x L x W): 70mm x 70mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 15 bar
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ¼ female (EN 837)
- Wetted parts made of stainless steel 316L
- Housing made of stainless steel with IP65 enclosure rating
- Overvoltage, short-circuit, and reverse polarity protection
- Fast response time under 4 ms
- High accuracy with ≤ ±1% of span
- Long service life with minimum 100 million load cycles
- Shock and vibration resistant according to IEC standards
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician familiar with pressure sensor integration and electrical safety standards.
Applications
- Measurement of liquid and gaseous media pressure
- Industrial process control requiring compound pressure measurement
- Use in environments with process temperatures from 0°C to 80°C
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life
- Low power consumption with efficient signal output
- Complies with RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK PBT-CB016SG2SS0ALA0Z Pressure Sensor is available for immediate purchase, ideal for industrial and process control applications requiring reliable pressure measurement.
