Pressure Transmitter PBT-CB1X0AG2SE0AMA0H | -1 to 0 Bar Range | IP67 Rated | 4-20mA Output | by SICK
The PBT-CB1X0AG2SE0AMA0H Pressure Transmitter is designed for accurate measurement of compound pressure from -1 bar to 0 bar, making it ideal for both liquid and gaseous media. With a robust stainless steel 316L construction and an IP67 rated enclosure, this sensor ensures durability in harsh industrial environments. Its fast response time of under 4 ms and high accuracy of ≤ ± 0.5 % span make it perfect for critical process control applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: -1 bar to 0 bar
- Pressure type: Compound pressure
- Process temperature: -30 °C to +100 °C
- Output signal: 4 mA to 20 mA, 2-wire
- Supply voltage: 8 V DC to 30 V DC
- Process connection: G ¼ female (EN 837)
- Wetted parts: 316L stainless steel
- Enclosure rating: IP67
- Accuracy: ≤ ± 0.5 % of span
- Response time: < 4 ms
- Shock load: 500 g
- Vibration resistance: 20 g
- Electrical safety: Overvoltage protection 32-36 V DC, short-circuit and reverse polarity protection
- MTTF: 815 years
- Service life: Minimum 100 million load cycles
- Dimensions (H x L x W): 70mm x 30mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 0 bar
- Suitable for liquid and gaseous media
- Process temperature range from -30 °C to +100 °C
- Output signal: 4 mA to 20 mA, 2-wire
- Vibration resistance up to 20 g
- Stainless steel 316L wetted parts and housing
- IP67 rated enclosure for dust and water protection
- Overvoltage and short-circuit protection
- High accuracy with ≤ ± 0.5 % span including non-linearity and hysteresis
- Fast response time under 4 ms
- Long service life with minimum 100 million load cycles
- Shock load resistance up to 500 g
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection and calibration according to industrial standards.
Applications
- Measurement of liquid and gaseous media pressure
- Industrial process control requiring compound pressure measurement
- Environments requiring vibration resistant and oil/grease free sensors
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life
- Low power consumption with efficient signal output
- Free from oil and grease, minimizing contamination risks
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK PBT-CB1X0AG2SE0AMA0H Pressure Sensor is available for immediate purchase, ideal for industrial process control and measurement applications.
